Intuitive switch point setting
The compact pressure sensor of the PK series can be used in nearly all industrial and mobile applications. Areas of application include liquid and gaseous media. Thanks to its high pressure peak resistance, resistance against aggressive media and high admissible burst pressure, the sensor can be used in hydraulics, pneumatics, air conditioning and refrigeration technology. The robustness of the stainless steel measuring cell ensures high long-term stability and wear-free operation over millions of pressure cycles. Switch point setting of the unit is easy and intuitive via a scaled setting ring (easy-turn). A scale shows the set pressure switch points. The unit can even be set before installation without system pressure being applied. Mechanical locking prevents unintentional maladjustment of the sensor. Two highly visible LEDs indicate the switching status and readiness for operation.
- Simple switch point setting by means of two setting rings allowing optimum reading
- Stainless steel measuring cell for chemical compatibility
- Mechanical locking prevents inadvertent switch point manipulation
- High bursting pressure
- For use in hydraulic and pneumatic applications
MPN | Measuring range | Process connection | Output signal | Electrical design | Medium temperature |
---|---|---|---|---|---|
PK5520 | 0...400 bar / 0...5800 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK5521 | 0...250 bar / 0...3625 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK5522 | 0...100 bar / 0...1450 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK5523 | 0...25 bar / 0...363 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK5524 | 0...10 bar / 0...145 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK5722 | 0...100 bar / 0...10 MPa | R 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6220 | 0...400 bar / 0...5800 psi | 1/4" NPT external thread | switching signal | PNP | -25...80 °C |
PK6222 | 0...100 bar / 0...1450 psi | 1/4" NPT external thread | switching signal | PNP | -25...80 °C |
PK6224 | 0...10 bar / 0...145 psi | 1/4" NPT external thread | switching signal | PNP | -25...80 °C |
PK6520 | 0...400 bar / 0...5800 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6521 | 0...250 bar / 0...3625 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6522 | 0...100 bar / 0...1450 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6523 | 0...25 bar / 0...363 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6524 | 0...10 bar / 0...145 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6530 | 0...400 bar / 0...40 MPa | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6531 | 0...250 bar / 0...25 MPa | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6532 | 0...100 bar / 0...10 MPa | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6732 | 0...100 bar / 0...10 MPa | R 1/4 external thread | switching signal | PNP | -25...80 °C |
PK6734 | 0...10 bar / 0...1000 kPa / 0...1 MPa | R 1/4 external thread | switching signal | PNP | -25...80 °C |
PK7520 | 0...400 bar / 0...5800 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK7521 | 0...250 bar / 0...3625 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK7522 | 0...100 bar / 0...1450 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK7524 | 0...10 bar / 0...145 psi | G 1/4 external thread | switching signal | PNP | -25...80 °C |
PK8530 | 0...400 bar / 0...40 MPa | G 1/4 external thread | switching signal | NPN | -25...80 °C |
PK8730 | 0...400 bar / 0...40 MPa | R 1/4 external thread | switching signal | NPN | -25...80 °C |
PK8731 | 0...250 bar / 0...25 MPa | R 1/4 external thread | switching signal | NPN | -25...80 °C |
PK8732 | 0...100 bar / 0...10 MPa | R 1/4 external thread | switching signal | NPN | -25...80 °C |
PK8734 | 0...10 bar / 0...1000 kPa / 0...1 MPa | R 1/4 external thread | switching signal | NPN | -25...80 °C |
