Process Sensors - Pressure & Vacuum - Pressure sensors / Vacuum sensors with display for pneumatic applications - Type PQ
Compact version with display for pneumatic applications
The PQ series pressure sensors are designed to monitor system pressure in pneumatic and compressed-air networks of machines and plants. The sensors can be used for both relative and differential pressure measurement. This makes them particularly suited for monitoring of filters for soiling or clogging. The measuring cell is insensitive to liquids or deposits that might occur in the system. It is overload protected and highly accurate. A 4-digit LED display, which can be seen from a distance and easily read, and two pushbuttons allow easy set-up, maintenance and operation of the sensor. The display can be switched from the indication of “red” to an alternating indication of “red – green”. So, switching states can be highlighted or an independent colour window can be created. Sensors with analogue output can also be configured via IO-Link, e.g. using a USB interface. The LINERECORDER SENSOR software is used to visualise, transfer and archive parameter sets.
- Clearly visible slanted LED display
- Two-color display of the process values to identify the acceptable range
- Easy installation with integrated mounting holes and accessories
- Two switching outputs, one of them programmable as analog output
- Pressure range -1...1 bar or -1...10 bar
MPN | Measuring range | Process connection | Output signal | Electrical design | Medium temperature |
---|---|---|---|---|---|
PQ0809 | -1...1 bar / -1000...1000 mbar | G 1/8 Internal thread | switching signal | NPN | 0...60 °C |
PQ0834 | -1...10 bar | G 1/8 Internal thread | switching signal | NPN | 0...60 °C |
PQ3809 | -1...1 bar / -1000...1000 mbar / -14.6...14.6 psi / -29.4...29.4 inHg / -100...100 kPa | G 1/8 Internal thread | switching signal; analog signal; IO-Link; (configurable) | PNP | 0...60 °C |
PQ3834 | -1...10 bar / -15...145 psi / -30...296 inHg / -100...1000 kPa | G 1/8 Internal thread | switching signal; analog signal; IO-Link; (configurable) | PNP | 0...60 °C |
PQ7809 | -1...1 bar / -1000...1000 mbar / -14.6...14.6 psi / -29.6...29.6 inHg / -100...100 kPa | G 1/8 Internal thread | switching signal | PNP | 0...60 °C |
PQ7834 | -1...10 bar / -15...145 psi / -30...296 inHg / -100...1000 kPa | G 1/8 Internal thread | switching signal | PNP | 0...60 °C |
