Headline
Full-metal housing with display for process technology
The flush pressure sensors of the PI27/PI28 series with full stainless steel housing are designed for use in process technology. They are resistant to high-pressure cleaning with aggressive cleaning agents. Their high protection rating IP 69K, a hygienic design and a high temperature resistance qualify the sensors for use in the food and pharmaceutical industries.
Features & Benefits
- High overall accuracy and electronic temperature compensation
- Programmable analog and switching output
- Hygienic, flush design
- Aseptoflex Vario - G 1 process connection with four sealing options
- High temperature resistance
Additional Notes
| MPN | Measuring range | Process connection | Output signal | Electrical design | Medium temperature |
|---|---|---|---|---|---|
| PI2602 | -1...100 bar / -15...1450 psi / -0.1...10 MPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2714 | -1...16 bar / -14.6...232 psi / -0.1...1.6 MPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2715 | -1...6 bar / -14.5...87 psi / -100...600 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2717 | -0.1...1.6 bar / -100...1600 mbar / -1.46...23.2 psi / -10...160 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2789 | -0.005...0.1 bar / -5...100 mbar / -2...40.16 inH2O / -0.5...10 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2793 | -1...25 bar / -14.4...362.7 psi / -0.1...2.5 MPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2794 | -1...10 bar / -14.5...145 psi / -0.1...1 MPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2795 | -1...4 bar / -14.5...58 psi / -100...400 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2796 | -0.124...2.5 bar / -124...2500 mbar / -1.8...36.27 psi / -12.4...250 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2797 | -0.05...1 bar / -50...1000 mbar / -0.73...14.5 psi / -5...100 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2798 | -0.0124...0.25 bar / -12.4...250 mbar / -5...100.4 inH2O / -1.24...25 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2799 | -1...1 bar / -1000...1000 mbar / -14.5...14.5 psi / -100...100 kPa | G 1 external thread Aseptoflex Vario | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2815 | -1...6 bar / -14.5...87 psi / -100...600 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2817 | -0.1...1.6 bar / -100...1600 mbar / -1.46...23.2 psi / -10...160 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2889 | -0.005...0.1 bar / -5...100 mbar / -2...40.16 inH2O / -0.5...10 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2893 | -1...25 bar / -14.4...362.7 psi / -0.1...2.5 MPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2894 | -1...10 bar / -14.5...145 psi / -0.1...1 MPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2895 | -1...4 bar / -14.5...58 psi / -100...400 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2896 | -0.124...2.5 bar / -124...2500 mbar / -1.8...36.27 psi / -12.4...250 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2897 | -0.05...1 bar / -50...1000 mbar / -0.73...14.5 psi / -5...100 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2898 | -0.0124...0.25 bar / -12.4...250 mbar / -5...100.4 inH2O / -1.24...25 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2899 | -1...1 bar / -1000...1000 mbar / -14.5...14.5 psi / -100...100 kPa | G 1 external thread sealing cone | switching signal; analog signal; IO-Link; (configurable) | PNP/NPN | -25...125; (145 max. 1h) °C |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-040010010 | Process Sensors - Pressure & Vacuum - Types PN / PE with digital display | $0.01 | |
| IFM-040010020 | Process Sensors - Pressure & Vacuum - Sensors with gauge display for Industrial and sanitary applications - Type PG | $0.01 | |
| IFM-040010040 | Process Sensors - Pressure & Vacuum - Sensors for high temperature with integrated triclamp for sanitary applications - Type PI | $0.01 | |
| IFM-040010050 | Process Sensors - Pressure & Vacuum - Flush mount transmitters for sanitary applications - Type PM | $0.01 | |
| IFM-040010060 | Process Sensors - Pressure & Vacuum - Pressure sensors / Vacuum sensors with display for pneumatic applications - Type PQ | $0.01 | |
| IFM-040010070 | Process Sensors - Pressure & Vacuum - Switches with adjustment dials - Type PK | $0.01 | |
| IFM-040010075 | Process Sensors - Pressure & Vacuum - Flush mountable for industrial applications | $0.01 | |
| IFM-040010080 | Process Sensors - Pressure & Vacuum - Transmitters with strain gauge technology - Type PT / PU | $0.01 | |
| IFM-040010090 | Process Sensors - Pressure & Vacuum - Transmitter with ceramic capacitive technology - Type PA and PX | $0.01 | |
| IFM-040010100 | Process Sensors - Pressure & Vacuum - Switches with ceramic capacitive technology - Type PP and PV | $0.01 | |
| IFM-040010110 | Process Sensors - Pressure & Vacuum - Transmitters for mobile applications | $0.01 | |
| IFM-040010120 | Process Sensors - Pressure & Vacuum - Flush mount transmitters for hydrostatic level applications - Type PI, PG and PM | $0.01 | |
| IFM-040010140 | Process Sensors - Pressure & Vacuum - Submersible transmitters for hydrostatic level - Type PS | $0.01 | |
| IFM-040010150 | Process Sensors - Pressure & Vacuum - Switches for differential pressure - Type PNI | $0.01 | |
| IFM-040010160 | Process Sensors - Pressure & Vacuum - Switches for gap detection | $0.01 |
