Rectangular inductive sensors
Rectangular inductive sensors are especially suited for conveying applications thanks to their long sensing ranges. To meet the demands of harsh industrial environments, each model comes with a robust plastic housing with high protection rating. The sensing face of the IM type sensor (40 x 40 mm) can be rotated in five different positions for flexible mounting even under adverse installation conditions. The two corner LEDs are clearly visible in any mounted position.
Inductive sensors of the I1 and I2 series have a large sensing area and particularly long sensing ranges. The sensing range can be easily set via potentiometer. This will prevent the sensor from detecting machine parts in the background. In steelworks positions of slabs, metal sheets or blocks are detected. The sensors operate just as reliably in these environments as in shearing or cutting applications.
Features & Benefits
- Long sensing ranges up to 120 mm
- Versions with connectors, terminals or connection cable
- Versions in three- and four-wire technology
- Type IM: Freely selectable sensing face with five positions; clearly visible corner LEDs
- Versions in AC or DCV
Additional Notes
| MPN | Sensing range | Switching frequency | Output function | Output | Dimensions |
|---|---|---|---|---|---|
| I15005 | 20...70 mm non-flush mountable | 5 Hz | complementary | DC PNP | Ø 100 / L = 40 mm |
| I17003 | 20...70 mm non-flush mountable | 5 Hz | normally open | DC PNP | Ø 100 / L = 45 mm |
| I22002 | 30...120 mm non-flush mountable | 3 Hz | normally closed | AC | Ø 164 / L = 63 mm |
| I27001 | 30...120 mm non-flush mountable | 3 Hz | normally open | DC PNP | Ø 164 / L = 63 mm |
| IB0004 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0011 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0012 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0017 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally closed | AC/DC | Ø 34 / L = 82 mm |
| IB0018 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally closed | AC/DC | Ø 34 / L = 82 mm |
| IB0026 | 30 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0027 | 30 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally closed | AC/DC | Ø 34 / L = 82 mm |
| IB0029 | 30 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0040 | 30 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0059 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0071 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0072 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open / closed; (selectable) | AC/DC | Ø 34 / L = 98 mm |
| IB0073 | 30 mm non-flush mountable | 25 Hz AC / 100 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0085 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0088 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally closed | AC/DC | Ø 34 / L = 82 mm |
| IB0121 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally open | AC/DC | Ø 34 / L = 82 mm |
| IB0122 | 20 mm non-flush mountable | 25 Hz AC / 50 Hz DC | normally closed | AC/DC | Ø 34 / L = 82 mm |
| IC0003 | 40 mm non-flush mountable | 10 Hz AC / 10 Hz DC | normally open / closed; (selectable) | AC/DC | 90 x 60 x 40 mm |
| IC0006 | 40 mm non-flush mountable | 10 Hz AC / 10 Hz DC | normally open / closed; (selectable) | AC/DC | |
| IC5005 | 40 mm non-flush mountable | 15 Hz | normally open / closed; (selectable) | DC PNP | 90 x 60 x 40 mm |
| IC5006 | 40 mm non-flush mountable | 15 Hz | normally open / closed; (selectable) | DC NPN | 90 x 60 x 40 mm |
| IC5007 | 40 mm non-flush mountable | 6 Hz | normally open | DC PNP | |
| ID0013 | 60 mm non-flush mountable | 4 Hz AC / 4 Hz DC | normally open / closed; (selectable) | AC/DC | 105 x 80 x 40 mm |
| ID0014 | 50 mm non-flush mountable | 25 Hz AC / 35 Hz DC | normally open | AC/DC | 120 x 80 x 30 mm |
| ID0015 | 50 mm non-flush mountable | 25 Hz AC / 35 Hz DC | normally closed | AC/DC | 120 x 80 x 30 mm |
| ID0036 | 60 mm non-flush mountable | 4 Hz AC / 4 Hz DC | normally open / closed; (selectable) | AC/DC | |
| ID0038 | 50 mm flush mountable | 25 Hz AC / 25 Hz DC | normally open | AC/DC | 92 x 80 x 40 mm |
| ID0039 | 50 mm flush mountable | 25 Hz AC / 25 Hz DC | normally open | AC/DC | 92 x 80 x 40 mm |
| ID3507 | 60 mm non-flush mountable | 4 Hz AC / 4 Hz DC | normally open / closed; (selectable , via internal terminals 4 + 5) | AC/DC | |
| ID5005 | 60 mm non-flush mountable | 100 Hz | normally open / closed; (selectable) | DC PNP | 105 x 80 x 40 mm |
| ID5023 | 60 mm non-flush mountable | 4 Hz | normally open / closed; (selectable) | DC NPN | 105 x 80 x 40 mm |
| ID5026 | 50 mm non-flush mountable | 100 Hz | normally open | DC PNP | 120 x 80 x 30 mm |
| ID5028 | 50 mm non-flush mountable | 8 Hz | normally open | DC NPN | 120 x 80 x 30 mm |
| ID5033 | 50 mm non-flush mountable | 100 Hz | normally open | DC PNP | 120 x 80 x 30 mm |
| ID5046 | 20...60 mm non-flush mountable | 100 Hz | normally open / closed; (selectable) | DC PNP | 105 x 80 x 40 mm |
| ID5055 | 50 mm flush mountable | 70 Hz | normally open | DC PNP | 92 x 80 x 40 mm |
| ID5059 | 50 mm flush mountable | 70 Hz | complementary | DC PNP | 92 x 80 x 40 mm |
| ID5063 | 50 mm non-flush mountable | 8 Hz | normally open | DC PNP | 120 x 80 x 30 mm |
| ID5075 | 50 mm flush mountable | 4 Hz | normally open | DC NPN | 92 x 80 x 40 mm |
| ID9922 | 50 mm flush mountable | 90 Hz | normally open | DC PNP/NPN | 92 x 80 x 40 mm |
| IM0011 | 15 mm flush mountable | 20 Hz AC / 55 Hz DC | normally open / closed; (selectable) | AC/DC | 40 x 40 x 120 mm |
| IM0013 | 20 mm non-flush mountable | 20 Hz AC / 55 Hz DC | normally open / closed; (selectable) | AC/DC | |
| IM001A | 20 mm flush mountable | 10 Hz AC / 10 Hz DC | normally open / closed; (selectable) | AC/DC | 40 x 40 x 105 mm |
| IM0020 | 15 mm flush mountable | 20 Hz AC / 55 Hz DC | normally open / closed; (selectable) | AC/DC | |
| IM002A | 40 mm non-flush mountable | 10 Hz AC / 10 Hz DC | normally open / closed; (selectable) | AC/DC | 40 x 40 x 105 mm |
| IM0041 | 35 mm non-flush mountable | 25 Hz AC / 100 Hz DC | normally open | AC/DC | |
| IM0042 | 35 mm non-flush mountable | 25 Hz AC / 100 Hz DC | normally open | AC/DC | |
| IM0053 | 35 mm non-flush mountable | 20 Hz AC / 50 Hz DC | normally open | AC/DC | 40 x 40 x 66 mm |
| IM0054 | 20 mm flush mountable | 25 Hz AC / 70 Hz DC | normally open | AC/DC | 40 x 40 x 66 mm |
| IM0055 | 20 mm flush mountable | 25 Hz AC / 100 Hz DC | normally open | AC/DC | 40 x 40 x 66 mm |
| IM0056 | 20 mm flush mountable | 25 Hz AC / 100 Hz DC | normally open | AC/DC | 40 x 40 x 66 mm |
| IM0057 | 35 mm non-flush mountable | 20 Hz AC / 50 Hz DC | normally closed | AC/DC | |
| IM5020 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5022 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5024 | 20 mm non-flush mountable | 300 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5033 | 15 mm flush mountable | 250 Hz | normally open | DC PNP | 40 x 40 x 120 mm |
| IM5037 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP/NPN | 40 x 40 x 120 mm |
| IM5038 | 20 mm non-flush mountable | 300 Hz | normally open / closed; (selectable) | DC PNP/NPN | 40 x 40 x 120 mm |
| IM5040 | 15 mm flush mountable | 350 Hz | normally open / closed; (selectable) | DC NPN | 40 x 40 x 120 mm |
| IM5041 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5044 | 20 mm non-flush mountable | 300 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5046 | 30 mm non-flush mountable | 100 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5052 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP | 40 x 40 x 120 mm |
| IM5054 | 15 mm flush mountable | 250 Hz | normally open / closed; (selectable) | DC PNP | |
| IM506A | 20 mm flush mountable | 100 Hz | normally open / closed; (selectable) | DC | 40 x 40 x 105 mm |
| IM5084 | 20 mm flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 66 mm |
| IM510A | 20 mm flush mountable | 100 Hz | complementary | DC | 40 x 40 x 105 mm |
| IM5115 | 20 mm flush mountable | 100 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5116 | 35 mm non-flush mountable | 80 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5117 | 40 mm non-flush mountable | 60 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5118 | 15 mm flush mountable | 100 Hz | DC AS-i | 40 x 40 x 54 mm | |
| IM5119 | 20 mm flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM511A | 40 mm non-flush mountable | 60 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5120 | 35 mm non-flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5123 | 20 mm flush mountable | 100 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5124 | 20 mm flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5125 | 35 mm non-flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5126 | 40 mm non-flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5127 | 15 mm flush mountable | 200 Hz | normally open | DC PNP/NPN | 40 x 40 x 54 mm |
| IM5128 | 20 mm flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5129 | 40 mm non-flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM512A | 20 mm flush mountable | 100 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5130 | 35 mm non-flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5131 | 40 mm non-flush mountable | 200 Hz | normally open | DC PNP | 40 x 40 x 54 mm |
| IM5132 | 20 mm flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5133 | 35 mm non-flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5134 | 35 mm non-flush mountable | 80 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5135 | 40 mm non-flush mountable | 200 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5136 | 40 mm non-flush mountable | 60 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IM5137 | 15 mm flush mountable | 200 Hz | normally closed | DC PNP/NPN | 40 x 40 x 54 mm |
| IM513A | 30 mm non-flush mountable | 100 Hz | complementary | DC PNP | 40 x 40 x 54 mm |
| IV0009 | 20 mm flush mountable | 30 Hz AC / 100 Hz DC | normally open / closed; (selectable) | AC/DC | 40 x 40 x 118 mm |
| IV5004 | 20 mm flush mountable | 400 Hz | complementary | DC PNP | 40 x 40 x 118 mm |
| IV5058 | 20 mm flush mountable | 300 Hz | complementary | DC PNP | 40 x 40 x 118 mm |
| IV5059 | 20 mm flush mountable | 300 Hz | complementary | DC PNP | 40 x 40 x 118 mm |
| IV5060 | 20 mm flush mountable | 5 Hz | normally open | DC PNP | 40 x 40 x 118 mm |
| IV5061 | 40 mm non-flush mountable | 180 Hz | complementary | DC PNP | 40 x 40 x 118 mm |
