Headline
Use in hazardous areas
The photoelectric sensors of type O5 comply with category 3D for use in zone 22 hazardous areas with non-conductive dusts. Sensors of category 3D can be connected directly to the plant control. The housings and housing parts of these units and of the corresponding connectors of the EVCxxA series were tested with an impact energy of 4 joules.
The product range includes through-beam sensors, retro-reflective and diffuse reflection sensors.
The sensors are compatible with the tried-and-tested mounting accessories and system components of the O5 series.
Features & Benefits
- Tried-and-tested photoelectric sensors for hazardous areas
- Long ranges
- Precise background suppression
- Setting process saves time and cost during set-up
- Extensive range of system components for easy and secure mounting
Additional Notes
| MPN | Transmitter / receiver | Dimensions | Range | Range referred to prismatic reflector | |
|---|---|---|---|---|---|
| O5E51A | Through-beam sensor | receiver | 105 x 30 x 62 mm | < 25 m | |
| O5H51A | Diffuse reflection sensor | 105 x 30 x 62 mm | 50...1800 mm | ||
| O5P51A | Retro-reflective sensor | 105 x 30 x 62 mm | 0.075...10 | ||
| O5S51A | Through-beam sensor | transmitter | 105 x 30 x 62 mm | < 25 m |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010050010 | Position Sensors - Photoelectric - OG M18 for industrial automation | $0.01 | |
| IFM-010050020 | Position Sensors - Photoelectric - OG M18 for high pressure cleaning applications | $0.01 | |
| IFM-010050030 | Position Sensors - Photoelectric - OG Cube for industrial automation | $0.01 | |
| IFM-010050040 | Position Sensors - Photoelectric - OG Cube for high pressure cleaning applications | $0.01 | |
| IFM-010050050 | Position Sensors - Photoelectric - O5 for industrial automation | $0.01 | |
| IFM-010050060 | Position Sensors - Photoelectric - O4 with long range for industrial automation | $0.01 | |
| IFM-010050070 | Position Sensors - Photoelectric - O6 for industrial automation | $0.01 | |
| IFM-010050080 | Position Sensors - Photoelectric - O6 wetline for harsh applications | $0.01 | |
| IFM-010050085 | Position Sensors - Photoelectric - O6 for coolant applications | $0.01 | |
| IFM-010050090 | Position Sensors - Photoelectric - O7 for industrial automation conveying applications | $0.01 | |
| IFM-010050095 | Position Sensors - Photoelectric - O8 for short range precise applications | $0.01 | |
| IFM-010050100 | Position Sensors - Photoelectric - OJ for industrial automation | $0.01 | |
| IFM-010050110 | Position Sensors - Photoelectric - OG basic for industrial automation | $0.01 | |
| IFM-010050120 | Position Sensors - Photoelectric - OG right angle for conveying applications | $0.01 | |
| IFM-010050150 | Position Sensors - Photoelectric - TW7 infrared temperature switches with display | $0.01 |
