Headline
Type M18 with light emission on the side
The photoelectric OG sensors in M18 housing offer additional installation options for applications where space is restricted due to the emission of the light beam on the side. A wide range of system components ensures easy and safe integration into the application.
The through-beam and retro-reflective sensors do not have to be set. They can be operated directly after mounting and adjustment and work safely and reliably. The visible red light facilitates the alignment of the sensors.
The diffuse reflection sensors have a fixed range and ensure precise background suppression.
Features & Benefits
- Space-saving design
- Fast installation and set-up
- Diffuse reflection sensor with precise background suppression
- Extensive range of system components for easy and secure mounting
Additional Notes
| MPN | Transmitter / receiver | Dimensions | Range | Range referred to prismatic reflector | |
|---|---|---|---|---|---|
| OG5123 | Diffuse reflection sensor | M18 x 1 / L = 65 mm | < 100 mm | ||
| OG5124 | Diffuse reflection sensor | M18 x 1 / L = 65 mm | < 200 mm | ||
| OG5125 | Retro-reflective sensor | M18 x 1 / L = 59.3 mm | 3 | ||
| OG5126 | Retro-reflective sensor | M18 x 1 / L = 59.3 mm | 3 | ||
| OG5127 | Through-beam sensor | receiver | M18 x 1 / L = 59.3 mm | < 9 m | |
| OG5128 | Through-beam sensor | receiver | M18 x 1 / L = 59.3 mm | < 9 m | |
| OG5129 | Through-beam sensor | transmitter | M18 x 1 / L = 59.3 mm | < 9 m | |
| OG5130 | Diffuse reflection sensor | M18 x 1 / L = 65 mm | < 70 mm |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010050010 | Position Sensors - Photoelectric - OG M18 for industrial automation | $0.01 | |
| IFM-010050020 | Position Sensors - Photoelectric - OG M18 for high pressure cleaning applications | $0.01 | |
| IFM-010050030 | Position Sensors - Photoelectric - OG Cube for industrial automation | $0.01 | |
| IFM-010050040 | Position Sensors - Photoelectric - OG Cube for high pressure cleaning applications | $0.01 | |
| IFM-010050050 | Position Sensors - Photoelectric - O5 for industrial automation | $0.01 | |
| IFM-010050060 | Position Sensors - Photoelectric - O4 with long range for industrial automation | $0.01 | |
| IFM-010050070 | Position Sensors - Photoelectric - O6 for industrial automation | $0.01 | |
| IFM-010050080 | Position Sensors - Photoelectric - O6 wetline for harsh applications | $0.01 | |
| IFM-010050085 | Position Sensors - Photoelectric - O6 for coolant applications | $0.01 | |
| IFM-010050090 | Position Sensors - Photoelectric - O7 for industrial automation conveying applications | $0.01 | |
| IFM-010050095 | Position Sensors - Photoelectric - O8 for short range precise applications | $0.01 | |
| IFM-010050100 | Position Sensors - Photoelectric - OJ for industrial automation | $0.01 | |
| IFM-010050110 | Position Sensors - Photoelectric - OG basic for industrial automation | $0.01 | |
| IFM-010050140 | Position Sensors - Photoelectric - Sensors for use in hazardous locations | $0.01 | |
| IFM-010050150 | Position Sensors - Photoelectric - TW7 infrared temperature switches with display | $0.01 |
