Headline
Type M18 in plastic housing
The photoelectric OG sensors in plastic housing are specially designed for position detection in conveying and handling applications.
The through-beam and retro-reflective sensors have fixed settings. This means cost-saving rapid up-time after quick installation with the optional accessories.
The diffuse reflection sensor has a potentiometer for fine-tuning in the application.
Features & Benefits
- For use in conveying and materials handling
- Low-cost alternative to units with metal housing
- Ready for operation immediately thanks to fixed setting
- Diffuse reflection sensor: Easy setting via potentiometer
- Extensive range of system components for easy and secure mounting
Additional Notes
| MPN | Product designation | Transmitter / receiver | Dimensions | Range | Range referred to prismatic reflector |
|---|---|---|---|---|---|
| OGE100 | Through-beam sensor | receiver | M18 x 1 / L = 44 mm | < 8 m | |
| OGE101 | Through-beam sensor | receiver | M18 x 1 / L = 44 mm | < 8 m | |
| OGE102 | Through-beam sensor | receiver | M18 x 1 / L = 44 mm | < 8 m | |
| OGE103 | Through-beam sensor | receiver | M18 x 1 / L = 44 mm | < 8 m | |
| OGP100 | Retro-reflective sensor | M18 x 1 / L = 44 mm | 0.05...2.5 | ||
| OGP101 | Retro-reflective sensor | M18 x 1 / L = 44 mm | 0.05...2.5 | ||
| OGP102 | Retro-reflective sensor | M18 x 1 / L = 44 mm | 0.05...2.5 | ||
| OGP103 | Retro-reflective sensor | M18 x 1 / L = 44 mm | 0.05...2.5 | ||
| OGS100 | Through-beam sensor | transmitter | M18 x 1 / L = 44 mm | < 8 m | |
| OGT100 | Diffuse reflection sensor | M18 x 1 / L = 44 mm | 10...400 mm | ||
| OGT101 | Diffuse reflection sensor | M18 x 1 / L = 44 mm | 10...400 mm | ||
| OGT102 | Diffuse reflection sensor | M18 x 1 / L = 44 mm | 10...400 mm | ||
| OGT103 | Diffuse reflection sensor | M18 x 1 / L = 44 mm | 10...400 mm |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010050010 | Position Sensors - Photoelectric - OG M18 for industrial automation | $0.01 | |
| IFM-010050020 | Position Sensors - Photoelectric - OG M18 for high pressure cleaning applications | $0.01 | |
| IFM-010050030 | Position Sensors - Photoelectric - OG Cube for industrial automation | $0.01 | |
| IFM-010050040 | Position Sensors - Photoelectric - OG Cube for high pressure cleaning applications | $0.01 | |
| IFM-010050050 | Position Sensors - Photoelectric - O5 for industrial automation | $0.01 | |
| IFM-010050060 | Position Sensors - Photoelectric - O4 with long range for industrial automation | $0.01 | |
| IFM-010050070 | Position Sensors - Photoelectric - O6 for industrial automation | $0.01 | |
| IFM-010050080 | Position Sensors - Photoelectric - O6 wetline for harsh applications | $0.01 | |
| IFM-010050085 | Position Sensors - Photoelectric - O6 for coolant applications | $0.01 | |
| IFM-010050090 | Position Sensors - Photoelectric - O7 for industrial automation conveying applications | $0.01 | |
| IFM-010050095 | Position Sensors - Photoelectric - O8 for short range precise applications | $0.01 | |
| IFM-010050100 | Position Sensors - Photoelectric - OJ for industrial automation | $0.01 | |
| IFM-010050120 | Position Sensors - Photoelectric - OG right angle for conveying applications | $0.01 | |
| IFM-010050140 | Position Sensors - Photoelectric - Sensors for use in hazardous locations | $0.01 | |
| IFM-010050150 | Position Sensors - Photoelectric - TW7 infrared temperature switches with display | $0.01 |
