Use in applications with coolants and lubricants
The photoelectric O6 coolant sensors are especially suited for applications in machine tools, metal working, conveyor technology and the automotive industry. The robust stainless steel housing with protection rating IP 68 / IP 69K is designed for use in harsh industrial environments.
The potentiometers and rotary switches are fitted with a double seal. In combination with the flush front pane, it guarantees optimum resistance to oils and coolants.
The transparent black housing cover ensures that, even in bright lighting conditions, the LEDs for switching status and operation are highly visible.
The diffuse reflection sensors provide reliable background suppression, even in cases of highly reflective backgrounds and objects like the oily and greasy metal surfaces of the parts to be worked. The sensing range is independent of the type and colour of the object to be detected.
- Robust stainless steel housing with high ingress resistance
- Diffuse reflection sensors with reliable background suppression
- Range is independent of the object color
- For use in metalworking and in the automotive industry
- High protection rating
| MPN | Product designation | Transmitter / receiver | Dimensions | Range | Range referred to prismatic reflector |
|---|---|---|---|---|---|
| O6E400 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6E401 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6E402 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6E403 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6E404 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6E405 | Through-beam sensor | receiver | 34.8 x 13 x 21 mm | < 10 m | |
| O6H400 | Diffuse reflection sensor | 41.3 x 13 x 21 mm | 2...200 mm | ||
| O6H401 | Diffuse reflection sensor | 41.3 x 13 x 21 mm | 2...200 mm | ||
| O6H402 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 2...200 mm | ||
| O6H403 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 2...200 mm | ||
| O6H404 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 2...200 mm | ||
| O6H405 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 2...200 mm | ||
| O6P400 | Retro-reflective sensor | 41.3 x 13 x 21 mm | 0.05...5 | ||
| O6P401 | Retro-reflective sensor | 41.3 x 13 x 21 mm | 0.05...5 | ||
| O6P402 | Retro-reflective sensor | 34.8 x 13 x 21 mm | 0.05...5 | ||
| O6P403 | Retro-reflective sensor | 34.8 x 13 x 21 mm | 0.05...5 | ||
| O6P404 | Retro-reflective sensor | 34.8 x 13 x 21 mm | 0.05...5 | ||
| O6P405 | Retro-reflective sensor | 34.8 x 13 x 21 mm | 0.05...5 | ||
| O6S400 | Through-beam sensor | transmitter | 34.8 x 13 x 21 mm | < 10 m | |
| O6S401 | Through-beam sensor | transmitter | 34.8 x 13 x 21 mm | < 10 m | |
| O6S402 | Through-beam sensor | transmitter | 34.8 x 13 x 21 mm | < 10 m | |
| O6T400 | Diffuse reflection sensor | 41.3 x 13 x 21 mm | 5...500 mm | ||
| O6T401 | Diffuse reflection sensor | 41.3 x 13 x 21 mm | 5...500 mm | ||
| O6T402 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 5...500 mm | ||
| O6T403 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 5...500 mm | ||
| O6T404 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 5...500 mm | ||
| O6T405 | Diffuse reflection sensor | 34.8 x 13 x 21 mm | 5...500 mm |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010050010 | Position Sensors - Photoelectric - OG M18 for industrial automation | $0.01 | |
| IFM-010050020 | Position Sensors - Photoelectric - OG M18 for high pressure cleaning applications | $0.01 | |
| IFM-010050030 | Position Sensors - Photoelectric - OG Cube for industrial automation | $0.01 | |
| IFM-010050040 | Position Sensors - Photoelectric - OG Cube for high pressure cleaning applications | $0.01 | |
| IFM-010050050 | Position Sensors - Photoelectric - O5 for industrial automation | $0.01 | |
| IFM-010050060 | Position Sensors - Photoelectric - O4 with long range for industrial automation | $0.01 | |
| IFM-010050070 | Position Sensors - Photoelectric - O6 for industrial automation | $0.01 | |
| IFM-010050080 | Position Sensors - Photoelectric - O6 wetline for harsh applications | $0.01 | |
| IFM-010050090 | Position Sensors - Photoelectric - O7 for industrial automation conveying applications | $0.01 | |
| IFM-010050095 | Position Sensors - Photoelectric - O8 for short range precise applications | $0.01 | |
| IFM-010050100 | Position Sensors - Photoelectric - OJ for industrial automation | $0.01 | |
| IFM-010050110 | Position Sensors - Photoelectric - OG basic for industrial automation | $0.01 | |
| IFM-010050120 | Position Sensors - Photoelectric - OG right angle for conveying applications | $0.01 | |
| IFM-010050140 | Position Sensors - Photoelectric - Sensors for use in hazardous locations | $0.01 | |
| IFM-010050150 | Position Sensors - Photoelectric - TW7 infrared temperature switches with display | $0.01 |
