Headline
Rectangular O5 design for factory automation
The photoelectric sensors of the O5 series are distinguished by long ranges, a versatile installation and mounting concept and an attractive price-performance ratio. The red light, infrared light and laser variants of this product line are available as through-beam, retro-reflective or diffuse reflection sensor types. The sensors are fast and easy to mount. Various fixing elements allow for an optimal adaptation to the particular installation situation.
Connector units are equipped with a connector that can be rotated by 270° for free alignment in any direction.
In demanding applications, precise adjustment to the application is made via potentiometer or pushbutton. Sensors with fixed settings allow immediate set-up.
Features & Benefits
- Very long ranges
- Precise background suppression
- Easy setting by teaching the "on" and "off" states
- Long range with and without sensitivity adjustment
- Extensive range of system components for easy and secure mounting
Additional Notes
| MPN | Product designation | Transmitter / receiver | Dimensions | Range | Range referred to prismatic reflector |
|---|---|---|---|---|---|
| O5E200 | Through-beam sensor | receiver | 56 x 18.2 x 46.8 mm | < 20 m | |
| O5E500 | Through-beam sensor | receiver | 56 x 18.2 x 46.8 mm | < 25 m | |
| O5E501 | Through-beam sensor | receiver | 56 x 18.2 x 46.8 mm | < 25 m | |
| O5E502 | Through-beam sensor | receiver | 56 x 18.2 x 46.8 mm | < 25 m | |
| O5G500 | Retro-reflective sensor for the detection of transparent objects | 56 x 18.2 x 46.8 mm | 0...3 | ||
| O5H200 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1400 mm | ||
| O5H201 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1400 mm | ||
| O5H205 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1400 mm | ||
| O5H500 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1800 mm | ||
| O5H501 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 60...700 mm | ||
| O5H503 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1800 mm | ||
| O5H504 | Diffuse reflection sensor | 56 x 18.2 x 46.8 mm | 50...1800 mm | ||
| O5P200 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.1...7 | ||
| O5P201 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.1...7 | ||
| O5P202 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.1...7 | ||
| O5P203 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.1...7 | ||
| O5P500 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.075...10 | ||
| O5P501 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.075...10 | ||
| O5P502 | Retro-reflective sensor | 56 x 18.2 x 46.8 mm | 0.075...10 | ||
| O5S200 | Through-beam sensor | transmitter | 56 x 18.2 x 46.8 mm | < 20 m | |
| O5S500 | Through-beam sensor | transmitter | 56 x 18.2 x 46.8 mm | < 25 m | |
| O5S501 | Through-beam sensor | transmitter | 56 x 18.2 x 46.8 mm | < 25 m |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010050010 | Position Sensors - Photoelectric - OG M18 for industrial automation | $0.01 | |
| IFM-010050020 | Position Sensors - Photoelectric - OG M18 for high pressure cleaning applications | $0.01 | |
| IFM-010050030 | Position Sensors - Photoelectric - OG Cube for industrial automation | $0.01 | |
| IFM-010050040 | Position Sensors - Photoelectric - OG Cube for high pressure cleaning applications | $0.01 | |
| IFM-010050060 | Position Sensors - Photoelectric - O4 with long range for industrial automation | $0.01 | |
| IFM-010050070 | Position Sensors - Photoelectric - O6 for industrial automation | $0.01 | |
| IFM-010050080 | Position Sensors - Photoelectric - O6 wetline for harsh applications | $0.01 | |
| IFM-010050085 | Position Sensors - Photoelectric - O6 for coolant applications | $0.01 | |
| IFM-010050090 | Position Sensors - Photoelectric - O7 for industrial automation conveying applications | $0.01 | |
| IFM-010050095 | Position Sensors - Photoelectric - O8 for short range precise applications | $0.01 | |
| IFM-010050100 | Position Sensors - Photoelectric - OJ for industrial automation | $0.01 | |
| IFM-010050110 | Position Sensors - Photoelectric - OG basic for industrial automation | $0.01 | |
| IFM-010050120 | Position Sensors - Photoelectric - OG right angle for conveying applications | $0.01 | |
| IFM-010050140 | Position Sensors - Photoelectric - Sensors for use in hazardous locations | $0.01 | |
| IFM-010050150 | Position Sensors - Photoelectric - TW7 infrared temperature switches with display | $0.01 |
