Illuminated touch sensors in M22 design
Capacitive touch sensors can be used, for example, as a start and stop button on machines, as enable switches and for opening and closing gates. Compared to mechanical switches the sensors operate without wear. Dynamic touch sensors detect an approaching human hand and suppress interference such as water, layers of ice or foreign bodies to a large extent. However, a gloved hand will still trigger them. Static touch sensors detect hands and objects even through glass for as long as the sensing face is covered which provides, for example, protection against vandalism. With the latching operating principle it is possible to switch the sensor on by touching briefly and to switch it off again by touching briefly again. The housing with protection rating IP 69K is resistant to oils and also impact and scratch resistant. Powerful LEDs as optical feedback signal that the sensor has been activated. The green LEDs can be controlled separately and, for example, be used to indicate the status of plant and machinery.
The sensor can be installed in all housings with a Ø 22.5 mm hole.
- Ergonomic working by softly touching the sensor
- Start-up delay prevents unintentional switching
- Plant condition indicated via RGB LEDs
- Various setting options such as color, NO/NC or triggering via IO-Link
- Adjustable brightness and sensitivity in wet environments or when operators wear gloves
MPN | Principle of operation | Output function | Output | Dimensions | Connection |
---|---|---|---|---|---|
KT5102 | dynamic | normally open | DC PNP | Ø 29 / L = 31 mm | 0.3 m PUR-Cable; M12 Connector |
KT6100 | dynamic; (static; Bistable configurable) | normally open / closed | DC PNP/NPN | 2 m PUR-Cable | |
KT6101 | dynamic; (static; Bistable configurable) | normally open / closed | DC PNP/NPN | 0.3 m PUR-Cable; M12 Connector | |
KT6300 | dynamic; (static; Bistable configurable) | normally open / closed | DC PNP/NPN | Ø 32 / L = 39 mm | 2 m PUR-Cable |
KT6301 | dynamic; (static; Bistable configurable) | normally open / closed | DC PNP/NPN | Ø 32 / L = 39 mm | 0.3 m PUR-Cable; M12 Connector |
SKU | Description | List price | - |
---|---|---|---|
IFM-010020010 | Position Sensors - Capacitive - Industrial automation applications | $0.01 | |
IFM-010020015 | Position Sensors - Capacitive - Non-contact level measurement | $0.01 | |
IFM-010020020 | Position Sensors - Capacitive - Sensors with metal housings | $0.01 | |
IFM-010020030 | Position Sensors - Capacitive - Low dielectric media applications | $0.01 | |
IFM-010020040 | Position Sensors - Capacitive - Sensors for high temperature applications | $0.01 | |
IFM-010020050 | Position Sensors - Capacitive - Sensors for aggressive media | $0.01 | |
IFM-010020060 | Position Sensors - Capacitive - Hazardous environments | $0.01 | |
IFM-010020070 | Position Sensors - Capacitive - Small rectangular housings | $0.01 | |
IFM-010020080 | Position Sensors - Capacitive - M12 sensors for industrial automation | $0.01 | |
IFM-010020090 | Position Sensors - Capacitive - IO-Link enabled sensors | $0.01 | |
IFM-010020095 | Position Sensors - Capacitive - Sensors with LED display | $0.01 | |
IFM-010020100 | Position Sensors - Capacitive - Large rectangular housings | $0.01 | |
IFM-010020110 | Position Sensors - Capacitive - AC sensors | $0.01 | |
IFM-010020120 | Position Sensors - Capacitive - Touch sensors | $0.01 | |
IFM-010020150 | Position Sensors - Capacitive - Switching amplifiers for Namur sensors | $0.01 |
