Headline
Small rectangular designs
Capacitive sensors detect bulk materials or liquids through non-metallic vessel walls. Typical applications for product detection can be found in the semiconductor, paper and wood industries. The capacitive sensors of the KQ series can either be fixed on a flat surface or on tubes using mounting brackets and cable ties.
The parameters can either be set via the buttons on the sensor or via IO-Link interface.
Features & Benefits
- User-friendly communication via IO-Link
- Normally closed and normally open outputs available
- Clearly visible indication of the switching status
- Easy installation with mounting adapters and cable ties
Additional Notes
| MPN | Sensing range | Output function | Output | Dimensions | Connection |
|---|---|---|---|---|---|
| KQ5100 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 7 x 48 mm | 2 m PUR-Cable |
| KQ5101 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 7 x 48 mm | 0.1 m PUR-Cable; M12 Connector |
| KQ5102 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 7 x 48 mm | 0.04 m PUR-Cable; M8 Connector |
| KQ6001 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP/NPN | 20 x 14 x 48 mm | 2 m PVC-Cable |
| KQ6002 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 14 x 48 mm | 2 m PVC-Cable |
| KQ6003 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP/NPN | 20 x 14 x 48 mm | 0.04 m PVC-Cable; M8 Connector |
| KQ6004 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 14 x 48 mm | 0.04 m PVC-Cable; M8 Connector |
| KQ6005 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 14 x 48 mm | 0.1 m PVC-Cable; M12 Connector |
| KQ6006 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC NPN | 20 x 14 x 48 mm | 2 m PVC-Cable |
| KQ6010 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | 20 x 14 x 48 mm | 0.04 m PVC-Cable; M8 Connector |
| KQ6016 | 12 mm non-flush mountable | normally open / closed; (selectable) | DC NPN | 20 x 14 x 48 mm | 2 m PVC-Cable; M12 Connector |
