Headline
Coaxial tubes for level sensors
A coaxial tube is required for the LR level sensor to function correctly in low dielectric media. The coaxial tube offers effective protection against electromagnetic interference for the reliable detection of oils and oil-based media. In case of operation of the LR level sensor with a coaxial probe, no minimum distances to tank walls and structures in the tank need to be observed.
Features & Benefits
- For use in low dielectric media
- Efficient protection against electromagnetic interference
- Reliable detection of oils and oil-based media
- No minimum distance to the vessel wall required
Additional Notes
| MPN | Product designation | Design | Length | Process connection |
|---|---|---|---|---|
| E43211 | Coaxial tubes for level sensors | for level sensors LR | 240 mm | G 3/4 |
| E43212 | Coaxial tubes for level sensors | for level sensors LR | 450 mm | G 3/4 |
| E43213 | Coaxial tubes for level sensors | for level sensors LR | 700 mm | G 3/4 |
| E43215 | Coaxial tubes for level sensors | for level sensors LR | 1200 mm | G 3/4 |
| E43216 | Coaxial tubes for level sensors | for level sensors LR | 1400 mm | G 3/4 |
| E43217 | Coaxial tubes for level sensors | for level sensors LR | 1600 mm | G 3/4 |
| E43218 | Coaxial tubes for level sensors | for level sensors LR | 450 mm | 3/4" NPT |
| E43219 | Coaxial tubes for level sensors | for level sensors LR | 700 mm | 3/4" NPT |
| E43220 | Coaxial tubes for level sensors | for level sensors LR | 1000 mm | 3/4" NPT |
| E43221 | Coaxial tubes for level sensors | for level sensors LR | 1600 mm | 3/4" NPT |
| E43223 | Coaxial tubes for level sensors | for level sensors LR | 1200 mm | 3/4" NPT |
| E43224 | Coaxial tubes for level sensors | for level sensors LR | 1400 mm | 3/4" NPT |
| E43228 | Coaxial tubes for level sensors | for level sensors LR | 300 mm | G 3/4 |
| E43229 | Coaxial tubes for level sensors | for level sensors LR | 500 mm | G 3/4 |
| E43230 | Coaxial tubes for level sensors | for level sensors LR | 150 mm | G 3/4 |
| E43245 | Coaxial tubes for level sensors | Version without holes, for level sensors, LR | 1000 mm | G 3/4 |
| E43333 | Coaxial tubes for level sensors | slotted design, for level sensors, LR | 700 mm | G 3/4 |
| E43334 | Coaxial tubes for level sensors | slotted design, for level sensors, LR | 1200 mm | G 3/4 |
| E43336 | Coaxial tubes for level sensors | for level sensors LR | 800 mm | G 3/4 |
| E43354 | Coaxial tubes for level sensors | for level sensors LR | 210 mm | G 3/4 |
| E43355 | Coaxial tubes for level sensors | for level sensors LR | 265 mm | G 3/4 |
| E43356 | Coaxial tubes for level sensors | for level sensors, LR205x, LRx020 | 2000 mm | G 3/4 |
| E43377 | Coaxial tubes for level sensors | for level sensors LR | 240 mm | 3/4" NPT |
| E43378 | Coaxial tubes for level sensors | for level sensors LR | 2000 mm | 3/4" NPT |
