Pictures may not be actual SKU
Product details
Spot an error? Let us know!
Headline
Ethernet and patch cables
For set-up, parameter setting and process data exchange of the vision sensors the operating software is used. For the parameter setting and process interface, two protocols are available: TCP/IP and EtherNet/IP. An EtherNet patch cable is used to connect the sensor and the processor.
Features & Benefits
- Reliable connection technology for CAN bus participants
- High protection rating for the requirements of harsh industrial environments
- Wide operating temperature range
- Shielded PUR cable
Additional Notes
| MPN | Product designation | Connection | Cable structure | Display | Number of cores |
|---|---|---|---|---|---|
| E11898 | Connection cable | 2 m PVC-Cable; M12 / RJ45 Connector | 4 x 0,38 mm² | 4 | |
| E12090 | Connection cable | 2 m PVC-Cable; M12 / RJ45 Connector | 2 x 2 x 0,38 mm² | ||
| E12204 | Connection cable | 10 m PVC-Cable; M12 / RJ45 Connector | 4 x 0,38 mm² | 4 | |
| E12205 | Connection cable | 20 m PVC-Cable; M12 / RJ45 Connector | 4 x 0,38 mm² | 4 | |
| E12226 | Connection cable | 2 m PVC-Cable; M12 / RJ45 Connector | 4 x 0,38 mm² | 4 | |
| E12283 | Connection cable | 5 m PVC-Cable; M12 / RJ45 Connector | 4 x 0,38 mm² | 4 | |
| E12289 | Wirable plug | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E12354 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E12422 | Connection cable | 0.5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12423 | Connection cable | 20 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12424 | Connection cable | 20 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12490 | Connection cable | 0.5 m PVC-Cable; M12 / RJ45 Connector | 2 x 2 x 0,38 mm² | ||
| E12491 | Connection cable | 5 m PVC-Cable; M12 / RJ45 Connector | 2 x 2 x 0,38 mm² | ||
| E12492 | Connection cable | 10 m PVC-Cable; M12 / RJ45 Connector | 2 x 2 x 0,38 mm² | ||
| E12493 | Connection cable | 20 m PVC-Cable; M12 / RJ45 Connector | 2 x 2 x 0,38 mm² | ||
| E12510 | Male cordsets | 2 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12511 | Male cordsets | 5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12512 | Male cordsets | 10 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12513 | Male cordsets | 20 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E12514 | Wirable plug | RJ45 Connector; insulation displacement terminals: 0,34 mm²; Cable sheath: Ø 4,5...8 mm | |||
| E18422 | Connection cable | 5 m PUR-Cable; M12 / RJ45 Connector | 2 x 0,38 mm² | 2 | |
| E18423 | Connection cable | 10 m PUR-Cable; M12 / RJ45 Connector | 2 x 0,38 mm² | 2 | |
| E21137 | Connection cable | 10 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E21138 | Connection cable | 2 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E21139 | Connection cable | 5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| E21140 | Adapter | M12 / RJ45 Connector | |||
| E80412 | 0.5 m; M12 Connector | ||||
| UC0234 | Connection cable | 1 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| ZH4114 | Connection cable | 5 m PVC-Cable; M12 / RJ45 Connector | 4 x 2x0,14 mm² | 4 | |
| ZH4115 | Connection cable | 2 m PVC-Cable; M12 / RJ45 Connector | 4 x 2x0,14 mm² | 4 | |
| ZH4116 | Connection cable | 10 m PVC-Cable; M12 / RJ45 Connector | 4 x 2x0,14 mm² | 4 |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-090010010 | Cables and Connections - Industrial - Female cordsets | $0.01 | |
| IFM-090010020 | Cables and Connections - Industrial - Male cordsets | $0.01 | |
| IFM-090010030 | Cables and Connections - Industrial - Patchcords | $0.01 | |
| IFM-090010040 | Cables and Connections - Industrial - Y/T-splitters | $0.01 | |
| IFM-090010050 | Cables and Connections - Industrial - Wiring blocks | $0.01 | |
| IFM-090010060 | Cables and Connections - Industrial - Female receptacles | $0.01 | |
| IFM-090010070 | Cables and Connections - Industrial - Male receptacles | $0.01 | |
| IFM-090010080 | Cables and Connections - Industrial - COMBICON connectors | $0.01 | |
| IFM-090010090 | Cables and Connections - Industrial - Female wirable connectors | $0.01 | |
| IFM-090010100 | Cables and Connections - Industrial - Male wirable connectors | $0.01 | |
| IFM-090010110 | Cables and Connections - Industrial - Patchcords with valve plug | $0.01 | |
| IFM-090010120 | Cables and Connections - Industrial - Y-splitters | $0.01 |
