Pictures may not be actual SKU
Product details
Spot an error? Let us know!
Headline
Female wirable connectors
Female wirable connectors are used for the connection of sensors or actuators with connectors. They are used if a specific cable length or cable is required. The connection is made via screw terminals, solder or crimp connections.
Features & Benefits
- Straight or right angle design
- Gold-plated contacts for reliable electrical connections
- Versions with LED for switching status indication and operation
- High protection rating for the requirements of harsh industrial environments
Additional Notes
| MPN | Product designation | Connection | Cable structure | Display | Number of cores |
|---|---|---|---|---|---|
| E10013 | Female wirable connectors | M18 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E1001A | Female wirable connectors | Rd24 Connector; terminals: ...2,5 mm²; Cable sheath: Ø 10...12 mm | |||
| E1003A | Female wirable connectors | M18 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E1004A | Female wirable connectors | Rd24 Connector; terminals: ...2,5 mm²; Cable sheath: Ø 6...8 mm | |||
| E10058 | Valve plug type A (according to DIN EN 175301-803) | valve plug type A DIN Connector; terminals: ...1,5 mm²; Cable sheath: Ø 6...8 mm | |||
| E10108 | Female wirable connectors | M12 Connector; screw terminals: ...0,5 mm² | |||
| E10109 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 4...6 mm | |||
| E10137 | Female wirable connectors | M18 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E10447 | Female wirable connectors | M23 Connector; soldering: ...1 mm²; Cable sheath: Ø 10...14 mm | |||
| E10886 | Female wirable connectors | M23 Connector; soldering: ...1 mm²; Cable sheath: Ø 10...14 mm | |||
| E10887 | Female wirable connectors | M23 Connector; soldering: ...1 mm²; Cable sheath: Ø 10...14 mm | |||
| E11043 | Female wirable connectors | Rd24 Connector; terminals: ...2,5 mm²; Cable sheath: Ø 6...8 mm | |||
| E11145 | Female wirable connectors | M12 Connector; insulation displacement technology: 0,34...0,75 mm²; (Ø ...2,5 mm); Cable sheath: Ø 4...7,5 mm | |||
| E11252 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E11510 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 4...6 mm | Switching status: 1 x LED yellow; Power: 1 x LED green | ||
| E11552 | Female wirable connectors | M8 Connector; insulation displacement technology: 0,14...0,38 mm²; (Ø 1,0...1,6 mm); Cable sheath: Ø 3...5 mm | |||
| E11553 | Female wirable connectors | M8 Connector; insulation displacement technology: 0,14...0,38 mm²; (Ø 1,0...1,6 mm); Cable sheath: Ø 3...5 mm | |||
| E11764 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 4...6 mm | |||
| E12224 | Valve plug type A (according to DIN EN 175301-803) | valve type A DIN Connector; terminals: ...1,5 mm²; Cable sheath: Ø 6...8 mm | |||
| E12356 | Female wirable connectors | M12 Connector; screw terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E12357 | Female wirable connectors | M8 Connector; screw terminals: 0,14...0,5 mm²; Cable sheath: Ø 3,5...5 mm | |||
| E12464 | Female wirable connectors | M8 Connector; screw terminals: 0,14...0,5 mm²; Cable sheath: Ø 3,5...5 mm | |||
| E12499 | Female wirable connectors | M12 Connector; screw terminals: 0,75...1,5 mm²; Cable sheath: Ø 8...10 mm | |||
| E12582 | Female wirable connectors | AMP connector Connector; terminals: 0,5 mm² / 0,25 mm² | |||
| E12583 | Female wirable connectors | DEUTSCH connector Connector; 0,5 mm² | |||
| E12672 | Female wirable connectors | M12 Connector; screw terminals: 1,5...2,5 mm²; Cable sheath: Ø 8...13 mm | |||
| E18059 | Female wirable connectors | M12 Connector; insulation displacement technology: 0,14...0,34 mm²; (Ø 1,0...1,55 mm); Cable sheath: Ø 4...5 mm | |||
| E18061 | Female wirable connectors | M12 Connector; insulation displacement technology: 0,14...0,34 mm²; (Ø 1,0...1,55 mm); Cable sheath: Ø 4...5 mm | |||
| E18161 | Female wirable connectors | M12 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E18164 | Female wirable connectors | M12 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 4...6 mm | |||
| E18165 | Female wirable connectors | M12 Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| E60122 | Female wirable connectors | M23 Connector; soldering: ...1 mm² | |||
| E60124 | Female wirable connectors | M23 Connector; soldering: ...1 mm² | |||
| E60136 | Female wirable connectors | M23 Connector; soldering: ...1 mm²; Cable sheath: Ø 4,5...6 mm | |||
| E60174 | Female wirable connectors | M18 Connector; soldering: ...0,25 mm²; Cable sheath: Ø 6...8 mm | |||
| E70142 | Female wirable connectors | Rd24 Connector; terminals: ...2,5 mm²; Cable sheath: Ø 10...12 mm | |||
| EVC810 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVC811 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVC814 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVC815 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVC816 | Wirable plug | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVF566 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVF569 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| EVF570 | Female wirable connectors | M12 Connector; screw terminals: 0,25...1 mm²; Cable sheath: Ø 3,5...6 mm | |||
| L34103 | Female wirable connectors | 1/2" Connector; terminals: ...0,75 mm²; Cable sheath: Ø 4...6 mm | |||
| L34106 | Female wirable connectors | 1/2" Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| L34107 | Female wirable connectors | 1/2" Connector; terminals: ...0,75 mm²; Cable sheath: Ø 6...8 mm | |||
| L34115 | Female wirable connectors | 7/8" Connector; terminals: ...1,5 mm²; Cable sheath: Ø 5...13 mm | |||
| L34121 | Female wirable connectors | 7/8" Connector; terminals: ...1,5 mm²; Cable sheath: Ø 5...13 mm |
