Self-monitoring transmitters
Thanks to the calibration check technology, the TCC permanently checks its own drift behaviour. The sensor compares the temperature value to the simultaneously measured reference value. If the deviation is outside the tolerance range, which can be set between 0.5 and 3 K, the TCC provides an optical signal and sends a message to the central controller via IO-Link and the diagnostic output. The same applies to cases of serious malfunctions.
Thanks to their hygienic design, high protection rating and integrated process connection, the sensors are particularly suited for applications in the food, beverage and pharmaceutical industries.
The sensors are available with different probe lengths and process connections. They can be configured via IO-Link, e.g. using a USB interface. The LR DEVICE software is used to visualise, transfer and archive parameter sets.
- Integrated drift monitoring and diagnostic function
- Free factory calibration certificate available
- High process reliability and plant uptime due to self-monitoring
- Short response time
- High precision of 0.2 K
MPN | Measuring range temperature | Factory setting | Output function | Analog output | Process connection |
---|---|---|---|---|---|
TCC201 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC231 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC241 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC261 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC281 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC291 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Diameter Ø 6 mm |
TCC501 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | G 1/2 sealing cone |
TCC511 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | G 1/2 sealing cone |
TCC531 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | G 1/2 sealing cone |
TCC541 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | G 1/2 sealing cone |
TCC551 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | G 1/2 sealing cone |
TCC811 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Clamp DN25...DN40 (1...1,5") |
TCC831 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Clamp DN25...DN40 (1...1,5") |
TCC911 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Clamp DN50 (2") |
TCC931 | -25...160 °C / -13...320 °F | -10...150 °C / 14...302 °F | normally closed; (diagnostic signal); analog | 4...20 mA | Clamp DN50 (2") |
SKU | Description | List price | - |
---|---|---|---|
IFM-040050010 | Process Sensors - Temperature - Transmitters with display for sanitary applications - Type TD | $0.01 | |
IFM-040050020 | Process Sensors - Temperature - Compact transmitters for general applications - Type TA | $0.01 | |
IFM-040050030 | Process Sensors - Temperature - Compact transmitters for sanitary applications - Type TA | $0.01 | |
IFM-040050035 | Process Sensors - Temperature - Compact transmitters for mobile machines | $0.01 | |
IFM-040050040 | Process Sensors - Temperature - Flush sensors for sanitary applications - Type TA / TM | $0.01 | |
IFM-040050060 | Process Sensors - Temperature - Cabled RTD probes - Type TS | $0.01 | |
IFM-040050070 | Process Sensors - Temperature - RTD probes - Type TM / TT | $0.01 | |
IFM-040050080 | Process Sensors - Temperature - RTD probes for sanitary applications - Type TM / TT | $0.01 | |
IFM-040050090 | Process Sensors - Temperature - Control monitors with display - Type TR | $0.01 | |
IFM-040050100 | Process Sensors - Temperature - Control monitors without display - Type TP | $0.01 | |
IFM-040050110 | Process Sensors - Temperature - Sensors with process connection, probe and display - Type TN | $0.01 | |
IFM-040050120 | Process Sensors - Temperature - Switches with adjustment dials - Type TK | $0.01 | |
IFM-040050130 | Process Sensors - Temperature - Thermowells | $0.01 | |
IFM-040050140 | Process Sensors - Temperature - Infrared temperature switches with display - Type TW7 | $0.01 | |
IFM-040050150 | Process Sensors - Temperature - Infrared transmitters with display - Type TW2 | $0.01 |
