Compact transmitters for industrial applications
The compact temperature transmitters are specially designed for use in process applications. They have an analog output with 4...20 mA. The Pt1000 measuring element of class A achieves a high precision with the factory-internal calibration. The innovation besides the wide measuring range is the excellent response time. Thanks to their high protection rating, fully welded stainless steel housing and high pressure resistance, the transmitters are particularly suited for use in harsh industrial environments. An LED clearly signals the readiness for operation. The sensors are available with different probe lengths, process connections and measuring ranges. A variety of adapters facilitates integration into the process. The units can either be used as 2-wire or 4-wire units. When used as a 4-wire unit, the transmitter can be configured via IO-Link, e.g. using a USB interface. The LR Device software is used to visualize, transfer and archive parameter sets.
- One-piece construction with wide measurement range
- Very short response time
- High mechanical stability and pressure resistance up to 400 bar
- High protection rating for the requirements of harsh industrial environments
- Installation lengths from 25…350 mm
| MPN | Measuring range temperature | Factory setting | Analog output | Process connection | Installation length EL |
|---|---|---|---|---|---|
| TA2105 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/4 | 25 mm |
| TA2115 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/4 | 50 mm |
| TA2135 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/4 | 100 mm |
| TA2145 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/4 | 150 mm |
| TA2212 | -50...200 °C | 0...200 °C | 4...20 mA | Diameter Ø 6 mm | 50 mm |
| TA2232 | -50...200 °C | 0...200 °C | 4...20 mA | Diameter Ø 6 mm | 100 mm |
| TA2241 | -50...200 °C | -10...150 °C | 4...20 mA | Diameter Ø 6 mm | 150 mm |
| TA2242 | -50...200 °C | 0...200 °C | 4...20 mA | Diameter Ø 6 mm | 150 mm |
| TA2262 | -50...200 °C | 0...200 °C | 4...20 mA | Diameter Ø 6 mm | 250 mm |
| TA2292 | -50...200 °C | 0...200 °C | 4...20 mA | Diameter Ø 6 mm | 350 mm |
| TA2303 | -58...302 °F | 0...300 °F | 4...20 mA | 1/2" NPT | 30 mm |
| TA2313 | -58...302 °F | 0...300 °F | 4...20 mA | 1/2" NPT | 50 mm |
| TA2333 | -58...302 °F | 0...300 °F | 4...20 mA | 1/2" NPT | 100 mm |
| TA2343 | -58...302 °F | 0...300 °F | 4...20 mA | 1/2" NPT | 150 mm |
| TA2345 | -50...150 °C | -50...150 °C | 4...20 mA | 1/2" NPT | 150 mm |
| TA2405 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/2 | 30 mm |
| TA2415 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/2 | 50 mm |
| TA2417 | -50...150 °C | 0...100 °C | 4...20 mA | G 1/2 | 50 mm |
| TA2435 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/2 | 100 mm |
| TA2437 | -50...150 °C | 0...100 °C | 4...20 mA | G 1/2 | 100 mm |
| TA2445 | -50...150 °C | -50...150 °C | 4...20 mA | G 1/2 | 150 mm |
| TA2447 | -50...150 °C | 0...100 °C | 4...20 mA | G 1/2 | 150 mm |
| TA2603 | -58...302 °F | 0...300 °F | 4...20 mA | 1/4" NPT | 25 mm |
| TA2613 | -58...302 °F | 0...300 °F | 4...20 mA | 1/4" NPT | 50 mm |
| TA2633 | -58...302 °F | 0...300 °F | 4...20 mA | 1/4" NPT | 100 mm |
| TA2643 | -58...302 °F | 0...300 °F | 4...20 mA | 1/4" NPT | 150 mm |
| TAA131 | -10...150 °C / 14...302 °F | G 1/4 external thread | 60 mm | ||
| TAA431 | -10...150 °C / 14...302 °F | G 1/2 external thread | 87.5 mm | ||
| TV7105 | -50...150 °C | G 1/4 | 25 mm | ||
| TV7303 | -58...302 °F | 1/2" NPT | 30 mm | ||
| TV7405 | -50...150 °C | G 1/2 | 30 mm | ||
| TV7603 | -58...302 °F | 1/4" NPT | 25 mm |
