Headline
Flush full-metal pressure sensors with display
The flush pressure sensors of the PI27/PI28 series with full stainless steel housing are designed for use in process technology. They are resistant to high-pressure cleaning with aggressive cleaning agents. Their high protection rating IP 69K, a hygienic design and a high temperature resistance qualify the sensors for use in the food and pharmaceutical industries. The units feature two switching outputs which can be programmed as normally open or normally closed. For output of the measured value, one switching output can also be configured as a scalable analog output. Parameter setting is effected via the buttons on the sensor. The highly visible display, combined with a user-friendly interface, enables fast and easy set-up. The sensor can also be configured via IO-Link, e.g. using a USB interface. The sensor can also be configured via IO-Link, e.g. using a USB interface. The LR Device software is used to visualize, transfer and archive parameter sets.
Features & Benefits
- High overall accuracy and electronic temperature compensation
- Programmable analog and switching output
- Hygienic, flush design
- Aseptoflex Vario - G 1 process connection with four sealing options
- High temperature resistance
Additional Notes
| MPN | Measuring range | Process connection | Output function | Electrical design | Medium temperature |
|---|---|---|---|---|---|
| PI2789 | -0.005...0.1 bar / -5...100 mbar / -2...40.16 inH2O / -0.5...10 kPa | G 1 external thread Aseptoflex Vario | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2796 | -0.124...2.5 bar / -124...2500 mbar / -1.8...36.27 psi / -12.4...250 kPa | G 1 external thread Aseptoflex Vario | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2797 | -0.05...1 bar / -50...1000 mbar / -0.73...14.5 psi / -5...100 kPa | G 1 external thread Aseptoflex Vario | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2798 | -0.0124...0.25 bar / -12.4...250 mbar / -5...100.4 inH2O / -1.24...25 kPa | G 1 external thread Aseptoflex Vario | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2799 | -1...1 bar / -1000...1000 mbar / -14.5...14.5 psi / -100...100 kPa | G 1 external thread Aseptoflex Vario | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2889 | -0.005...0.1 bar / -5...100 mbar / -2...40.16 inH2O / -0.5...10 kPa | G 1 external thread sealing cone | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2896 | -0.124...2.5 bar / -124...2500 mbar / -1.8...36.27 psi / -12.4...250 kPa | G 1 external thread sealing cone | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2897 | -0.05...1 bar / -50...1000 mbar / -0.73...14.5 psi / -5...100 kPa | G 1 external thread sealing cone | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2898 | -0.0124...0.25 bar / -12.4...250 mbar / -5...100.4 inH2O / -1.24...25 kPa | G 1 external thread sealing cone | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
| PI2899 | -1...1 bar / -1000...1000 mbar / -14.5...14.5 psi / -100...100 kPa | G 1 external thread sealing cone | normally open / closed; (configurable); analog | PNP/NPN | -25...125; (145 max. 1h) °C |
