Level sensors - With integrated temperature monitoring
The level sensors of the LT series enable reliable level and temperature monitoring in vessels and tanks. They are for example used to continuously measure the fill level of coolant containers or hydraulic reservoirs. The sensor displays either the current level or the current temperature and signals via two switching outputs that the set limits have been reached or that the level is below the set limit. Setting to the medium to be measured and adjustment of the switch-on and switch-off points and switching functions of the outputs is simple thanks to the intuitive user menu. The sensors are available with three different probe lengths. The immersion depth is easily adjusted using the optional screw-in or flange adapters. By combining level and temperature monitoring in one device, the need for an additional borehole in the tank for the second measuring system is eliminated.
- Reliable level detection in containers and tanks
- For use in water, oils and coolants
- User-friendly setting of switching function and switch points
- Level and temperature monitoring with just one unit
- Clearly visible numerical display
| MPN | Probe length L | Level measurement | Factory setting | Probe length | Electrical design |
|---|---|---|---|---|---|
| LT3022 | 264 mm | mineral oils | PNP/NPN | ||
| LT3023 | 472 mm | mineral oils | PNP/NPN | ||
| LT3024 | 728 mm | mineral oils | PNP/NPN | ||
| LT8022 | 264 mm | 0.025...0.221 m | 2 switching outputs level (OUT1, OUT2), 2 switching outputs temperature (OUT3, OUT4), mineral oils | PNP/NPN | |
| LT8023 | 472 mm | 0.04...0.429 m | 2 switching outputs level (OUT1, OUT2), 2 switching outputs temperature (OUT3, OUT4), mineral oils | PNP/NPN | |
| LT8024 | 728 mm | 0.05...0.636 m | 2 switching outputs level (OUT1, OUT2), 2 switching outputs temperature (OUT3, OUT4), mineral oils | PNP/NPN |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-040040010005 | Process Sensors - Level - Continuous - Capacitive non-contact level measurement | $0.01 | |
| IFM-040040010010 | Process Sensors - Level - Continuous - Capacitive probes - Type Lx | $0.01 | |
| IFM-040040010020 | Process Sensors - Level - Continuous - Guided wave radar probes - Type LR | $0.01 | |
| IFM-040040010030 | Process Sensors - Level - Continuous - Guided wave radar probes for sanitary applications - Type LR | $0.01 | |
| IFM-040040010040 | Process Sensors - Level - Continuous - Flush pressure sensors with display for sanitary applications - Type PI | $0.01 | |
| IFM-040040010050 | Process Sensors - Level - Continuous - Flush pressure sensors with gauge display for sanitary applications - Type PG | $0.01 | |
| IFM-040040010060 | Process Sensors - Level - Continuous - Flush pressure transmitters for sanitary applications - Type PM | $0.01 | |
| IFM-040040010080 | Process Sensors - Level - Continuous - Submersible pressure transmitters - Type PS | $0.01 | |
| IFM-040040010090 | Process Sensors - Level - Continuous - Non-contact distance measurement - Type O1D | $0.01 | |
| IFM-040040010100 | Process Sensors - Level - Continuous - Ultrasonic sensors | $0.01 | |
| IFM-040040020100 | Process Sensors - Level - Point level measurement -Capacitive probes - Type Lx | $0.01 | |
| IFM-040040020105 | Process Sensors - Level - Point level measurement - Residue suppression level switches for industrial applications - Type LM | $0.01 | |
| IFM-040040020110 | Process Sensors - Level - Point level measurement - Residue suppression level switches for sanitary applications - Type LM | $0.01 | |
| IFM-040040020120 | Process Sensors - Level - Point level measurement - Capacitive switches - Type K… | $0.01 | |
| IFM-040040020130 | Process Sensors - Level - Point level measurement - Evaluation units for level control | $0.01 |
