Temperature transmitters for hygienic applications
The compact temperature transmitters are specially designed for the food and beverage industry. They have an analogue output with 4...20 mA. The class A Pt1000 measuring element achieves a high precision with the factory-internal calibration. The innovation besides the wide measuring range is the excellent response time. Thanks to their high protection rating, fully welded stainless steel housing and high pressure resistance, the transmitters are particularly suited for use in hygienic environments. An LED clearly signals the readiness for operation. The sensors are available with different probe lengths, process connections and measuring ranges. A variety of adapters facilitates integration into the process. The units can either be used as 2-wire or 4-wire units. When used as a 4-wire unit, the transmitter can be configured via IO-Link, e.g. using a USB interface. The LINERECORDER SENSOR software is used to visualise, transfer and archive parameter sets.
- Hygienic design for the requirements of the food and beverage industry
- Very high dynamic response and short power-on delay time
- High precision across the entire temperature measurement range
- Precise analog output and user-friendly communication via IO-Link
- Robust stainless steel housing with high protection rating and high pressure resistance
MPN | Measuring range temperature | Factory setting | Output function | Process connection | Sensor connection |
---|---|---|---|---|---|
TA1101 | -50...200 °C | -10...150 °C | analog | M12 x 1,5 sealing cone | |
TA1102 | -50...200 °C | 0...200 °C | analog | M12 x 1,5 sealing cone | |
TA1107 | -50...200 °C | 0...100 °C | analog | M12 x 1,5 sealing cone | |
TA2002 | -50...200 °C | 0...200 °C | analog | Clamp DN10...DN20 (1/2...3/4") | |
TA2012 | -50...200 °C | 0...200 °C | analog | Clamp DN10...DN20 (1/2...3/4") | |
TA2212 | -50...200 °C | 0...200 °C | analog | Diameter Ø 6 mm | |
TA2232 | -50...200 °C | 0...200 °C | analog | Diameter Ø 6 mm | |
TA2241 | -50...200 °C | -10...150 °C | analog | Diameter Ø 6 mm | |
TA2242 | -50...200 °C | 0...200 °C | analog | Diameter Ø 6 mm | |
TA2262 | -50...200 °C | 0...200 °C | analog | Diameter Ø 6 mm | |
TA2292 | -50...200 °C | 0...200 °C | analog | Diameter Ø 6 mm | |
TA2502 | -50...200 °C | 0...200 °C | analog | G 1/2 sealing cone | |
TA2511 | -50...200 °C | -10...150 °C | analog | G 1/2 sealing cone | |
TA2512 | -50...200 °C | 0...200 °C | analog | G 1/2 sealing cone | |
TA2517 | -50...200 °C | 0...100 °C | analog | G 1/2 sealing cone | |
TA2531 | -50...200 °C | -10...150 °C | analog | G 1/2 sealing cone | |
TA2532 | -50...200 °C | 0...200 °C | analog | G 1/2 sealing cone | |
TA2537 | -50...200 °C | 0...100 °C | analog | G 1/2 sealing cone | |
TA2542 | -50...200 °C | 0...200 °C | analog | G 1/2 sealing cone | |
TA2802 | -50...200 °C | 0...200 °C | analog | Clamp DN25...DN40 (1...1,5") | |
TA2804 | 0...350 °F | analog | Clamp DN25...DN40 (1...1,5") | ||
TA2812 | -50...200 °C | 0...200 °C | analog | Clamp DN25...DN40 (1...1,5") | |
TA2814 | 0...350 °F | analog | Clamp DN25...DN40 (1...1,5") | ||
TA2832 | -50...200 °C | 0...200 °C | analog | Clamp DN25...DN40 (1...1,5") | |
TA2834 | 0...350 °F | analog | Clamp DN25...DN40 (1...1,5") | ||
TA2842 | -50...200 °C | 0...200 °C | analog | Clamp DN25...DN40 (1...1,5") | |
TA2844 | 0...350 °F | analog | Clamp DN25...DN40 (1...1,5") |
SKU | Description | List price | - |
---|---|---|---|
IFM-055060010010 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with digital display for industrial applications, Type PN and PE | $0.01 | |
IFM-055060010020 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Pressure sensors for hazardous areas | $0.01 | |
IFM-055060010030 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for sanitary applications, Type PI | $0.01 | |
IFM-055060010040 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors for high temperature with integrated triclamp for sanitary applications, Type PI | $0.01 | |
IFM-055060010050 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Switches for industrial automation, Type PP / PV | $0.01 | |
IFM-055060010060 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for pneumatic applications, Type PQ | $0.01 | |
IFM-055060020010 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Vortex flowmeter with display, Type SV | $0.01 | |
IFM-055060020020 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Mechatronic flowmeters with display, Type SB | $0.01 | |
IFM-055060020030 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Magnetic-inductive flowmeters, Type SM | $0.01 | |
IFM-055060020040 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Thermal flow switches, Type SI | $0.01 | |
IFM-055060020050 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Thermal flow sensors with display, Type SA | $0.01 | |
IFM-055060020060 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
IFM-055060030005 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Capacitive non-contact level measurement | $0.01 | |
IFM-055060030010 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Guided wave radar probes, Type LR | $0.01 | |
IFM-055060030020 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Guided wave radar probes for sanitary applications, Type LR | $0.01 |
