Compact flow sensors with display
The SA series flow sensors with display serve to monitor liquids and gases in pipes. In addition to volumetric flow monitoring, the SA also monitors the temperature of the medium. Thanks to a broad selection of process adapters, the sensors can be used in nearly all industrial applications. They are frequently used in cooling circuits, e.g. in steelworks, the automotive industry and in glassmaking. Further application areas include water management and cleaning processes in the food and beverage industry. Their robust stainless steel housing provides high reliability even in harsh operating conditions. Set-up, maintenance and operation are facilitated by a 4-digit LED display, which is visible from all sides even at greater distances, and two switching status LEDs on the sensor head. The display can be switched from the indication of "red" to an alternating indication of "red - green". So, switching states can be highlighted or an independent colour window can be created. Parameter setting is effected via the buttons on the sensor. The sensor can also be configured via IO-Link, e.g. using a USB interface. The LINERECORDER SENSOR software is used to visualise, transfer and archive parameter sets.
- Optimized for water, oils and air
- Measurement of flow and temperature at the same time
- Clearly visible LED display with red/green color change
- Adjustable inside pipe diameter from 25...400 mm
- The process connection can be rotated for optimum alignment
MPN | Process connection | Measuring range | Materials (wetted parts) | Electrical design | Output function |
---|---|---|---|---|---|
SA2000 | G 1/2 | stainless steel (1.4404 / 316L); Gasket: FKM | PNP/NPN | normally open / closed; (configurable); analog | |
SA2004 | G 1/2 | stainless steel (1.4404 / 316L); Gasket: FKM | analog | ||
SA4100 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | PNP/NPN | normally open / closed; (configurable); analog | |
SA4104 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | analog | ||
SA4114 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | analog | ||
SA4300 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | PNP/NPN | normally open / closed; (configurable); analog | |
SA4304 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | analog | ||
SA4314 | Diameter Ø 8 mm | stainless steel (1.4404 / 316L) | analog | ||
SA5000 | M18 x 1,5 Internal thread | stainless steel (1.4404 / 316L); Gasket: FKM | PNP/NPN | normally open / closed; (configurable); analog | |
SA5004 | M18 x 1,5 Internal thread | stainless steel (1.4404 / 316L); Gasket: FKM | analog | ||
SA5014 | M18 x 1,5 Internal thread | stainless steel (1.4404 / 316L); Gasket: FKM | analog |
SKU | Description | List price | - |
---|---|---|---|
IFM-055060010010 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with digital display for industrial applications, Type PN and PE | $0.01 | |
IFM-055060010020 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Pressure sensors for hazardous areas | $0.01 | |
IFM-055060010030 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for sanitary applications, Type PI | $0.01 | |
IFM-055060010040 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors for high temperature with integrated triclamp for sanitary applications, Type PI | $0.01 | |
IFM-055060010050 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Switches for industrial automation, Type PP / PV | $0.01 | |
IFM-055060010060 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for pneumatic applications, Type PQ | $0.01 | |
IFM-055060020010 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Vortex flowmeter with display, Type SV | $0.01 | |
IFM-055060020020 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Mechatronic flowmeters with display, Type SB | $0.01 | |
IFM-055060020030 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Magnetic-inductive flowmeters, Type SM | $0.01 | |
IFM-055060020040 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Thermal flow switches, Type SI | $0.01 | |
IFM-055060020060 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
IFM-055060030005 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Capacitive non-contact level measurement | $0.01 | |
IFM-055060030010 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Guided wave radar probes, Type LR | $0.01 | |
IFM-055060030020 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Guided wave radar probes for sanitary applications, Type LR | $0.01 | |
IFM-055060030030 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Residue suppression level switches for hazardous areas, Type LM | $0.01 |
