Level sensors with modular probe concept
The level sensor operates to the principle of guided wave radar and measures the level using electromagnetic pulses in the nanosecond range. It is suitable for continuous level monitoring of almost all liquids, including aqueous media, coolants, cleaning liquids and oils. The sensor is directly mounted in the tank using a process connection or flange plate. If necessary, the probe can be easily shortened and adapted to the tank by the user. Setting of all parameters as well as programming of the switch points and indication of the current level are carried out via pushbuttons and a 4-digit alphanumeric display. The sensor can also be configured via IO-Link, e.g. using a USB interface. The LINERECORDER SENSOR software is used to visualise, transfer and archive parameter sets.
- For the reliable level control in tanks and containers
- Probes may be cut to length for application flexibility
- Suitable for water, oils and coolants
- Clearly visible numerical display
- Precise analog output and user-friendly communication via IO-Link
MPN | Probe length L | Level measurement | Factory setting | Probe length | Electrical design |
---|---|---|---|---|---|
LR2050 | 150...2000 mm | 0.02...1.98 m | PNP/NPN | ||
LR2350 | 150...2000 mm | PNP/NPN | |||
LR2750 | 150...2000 mm | 0.02...1.98 m | PNP/NPN | ||
LR3000 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR3020 | 100...2000 mm | PNP/NPN | |||
LR3300 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR3320 | 100...2000 mm | PNP/NPN | |||
LR7000 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR7020 | 100...2000 mm | PNP/NPN | |||
LR7300 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR7320 | 100...2000 mm | PNP/NPN | |||
LR8000 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR8020 | 100...2000 mm | PNP/NPN | |||
LR8300 | 100...1600 mm | 0.02...1.58 m | PNP | ||
LR8320 | 100...2000 mm | PNP/NPN | |||
LR9020 | 100...1600 mm | 0.02...1.58 m | PNP |
SKU | Description | List price | - |
---|---|---|---|
IFM-055060010010 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with digital display for industrial applications, Type PN and PE | $0.01 | |
IFM-055060010020 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Pressure sensors for hazardous areas | $0.01 | |
IFM-055060010030 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for sanitary applications, Type PI | $0.01 | |
IFM-055060010040 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors for high temperature with integrated triclamp for sanitary applications, Type PI | $0.01 | |
IFM-055060010050 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Switches for industrial automation, Type PP / PV | $0.01 | |
IFM-055060010060 | IO-Link - IO-Link process sensors - IO-Link - Pressure sensors / IO-Link - Sensors with display for pneumatic applications, Type PQ | $0.01 | |
IFM-055060020010 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Vortex flowmeter with display, Type SV | $0.01 | |
IFM-055060020020 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Mechatronic flowmeters with display, Type SB | $0.01 | |
IFM-055060020030 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Magnetic-inductive flowmeters, Type SM | $0.01 | |
IFM-055060020040 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Thermal flow switches, Type SI | $0.01 | |
IFM-055060020050 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Thermal flow sensors with display, Type SA | $0.01 | |
IFM-055060020060 | IO-Link - IO-Link process sensors - IO-Link flow sensors - flow meters / IO-Link - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
IFM-055060030005 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Capacitive non-contact level measurement | $0.01 | |
IFM-055060030020 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Guided wave radar probes for sanitary applications, Type LR | $0.01 | |
IFM-055060030030 | IO-Link - IO-Link process sensors - IO-Link - Level sensors / IO-Link - Residue suppression level switches for hazardous areas, Type LM | $0.01 |
