Systems for the consumption measurement of compressed air & industrial gases
The compressed air meter of the SD series monitors the standard volume flow of compressed air in industrial use. It detects the four process categories flow velocity, volumetric flow quantity, consumed quantity and medium temperature. The sensor delivers reliable process values even in case of temperature or pressure fluctuations. The high accuracy of the sensor enables reliable detection of even the smallest quantities or leakages. Peak consumption, present consumption or accumulated consumption can be accessed and adjusted via programmed switch and alarm level settings - all at the touch of a button. The units feature two switching outputs which can be programmed as normally open or normally closed. For output of the measured value, one switching output can also be configured as a scalable analogue output. For consumed quantity monitoring, the other output transmits counting pulses to the controller. Parameter setting is effected via the buttons on the sensor. Some sensor types can additionally be configured via IO-Link, e.g. using a USB interface. The LINERECORDER SENSOR software is used to visualise, transfer and archive parameter sets.
- Precise measurement of flow, consumption and medium temperature
- For compressed air in industrial use as well as argon (Ar), carbon dioxide (CO2), nitrogen (N2), helium (He)
- High accuracy, repeatability and measurement dynamics
- With switching output, analog output and pulse output
- Clearly visible numerical display
MPN | Process connection | Measuring range | Materials (wetted parts) | Electrical design | Output function |
---|---|---|---|---|---|
SD0523 | G 1 Internal thread | 0.5...143.9 m/s / 8...2110 m³/h / 0.12...35.18 m³/min | stainless steel (1.4401 / 316); stainless steel (1.4301 / 304); ceramics glass passivated; PEEK; polyester; FKM | PNP | normally open / closed; (configurable); analog |
SD1540 | G 1 Internal thread | 0.6...143.9 m/s / 0.3...26260 m³/h / 0.005...437.6 m³/min | stainless steel (1.4301 / 304); stainless steel (1.4404 / 316L); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD2000 | R 2 DN50 | 0.3...95.2 m/s / 3...700 m³/h / 0.04...11.66 m³/min | stainless steel (1.4301 / 304): ; FKM; ceramics: glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD2500 | R 2 DN50 | 40...11670 l/min / 0.3...84 m/s / 2.5...700 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD2501 | 2" NPT DN50 | 80...24720 scfh / 1.5...412 scfm / 1...275.6 ft/s | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD5000 | G 1/4 DN8 | 1...250 l/min / 0.3...82.9 m/s / 0.04...15 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD5100 | G 1/4 DN8 | [Ar]: 0.08...24.04 m³/h; [CO2]: 0.04...14.36 m³/h; [N2]: 0.04...15 m³/h | stainless steel (1.4301 / 304); ceramics glass passivated; PEEK; polyester; FKM; aluminum anodized | PNP | normally open / closed; (configurable); analog |
SD5500 | G 1/4 DN8 | 0.8...250 l/min / 0.3...82.9 m/s / 0.05...15 m³/h | EN AW-6082 (aluminium); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD5600 | G 1/4 DN8 | 0.8...250 l/min / 0.3...82.9 m/s / 0.05...15 m³/h | EN AW-6082 (aluminium); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD5800 | G 1/4 DN8 | 0.8...83.4 l/min / 0.3...27.6 m/s / 0.05...5 m³/h | EN AW-6082 (aluminium); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD6000 | R 1/2 DN15 | 10...1250 l/min / 0.3...103.6 m/s / 0.2...75 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD6050 | G 1/2 DN15 | 10...1250 l/min / 0.3...103.6 m/s / 0.2...75 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD6100 | R 1/2 DN15 | [Ar]: 0.4...122 m³/h; [CO2]: 0.2...74.7 m³/h; [N2]: 0.2...75 m³/h | stainless steel (1.4301 / 304); ceramics glass passivated; PEEK; polyester; FKM; aluminum anodized | PNP | normally open / closed; (configurable); analog |
SD6101 | 1/2" NPT DN15 | [Ar]: 15...4310 scfh / 0.2...71.8 scfm / 2...552 sfs; [CO2]: 10...2640 scfh / 0.15...44 scfm / 1...338.5 sfs; [N2]: 10...2650 scfh / 0.15...44.15 scfm / 1...339.5 sfs | stainless steel (1.4301 / 304); ceramics glass passivated; PEEK; polyester; FKM; aluminum anodized | PNP | normally open / closed; (configurable); analog |
SD6500 | R 1/2 DN15 | 4...1250 l/min / 0.3...99.8 m/s / 0.25...75 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD6501 | 1/2" NPT DN15 | 8...2648 scfh / 0.15...44.15 scfm / 1...327.4 ft/s | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD6600 | R 1/2 DN15 | 4...1250 l/min / 0.3...99.8 m/s / 0.25...75 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD6601 | 1/2" NPT DN15 | 8...2648 scfh / 0.15...44.15 scfm / 1...327.4 ft/s | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD6800 | R 1/2 DN15 | 1.5...166.5 l/min / 0.1...13.3 m/s / 0.1...10 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD8000 | R 1 DN25 | 13...3750 l/min / 0.4...109.2 m/s / 0.7...225 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD8100 | R 1 DN25 | [Ar]: 1.2...366.6 m³/h; [CO2]: 0.8...223.6 m³/h; [N2]: 0.8...225 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK-GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD8500 | R 1 DN25 | 14...3750 l/min / 0.4...103.7 m/s / 0.8...225 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD8501 | 1" NPT DN25 | 25...7945 scfh / 0.4...132.4 scfm / 1.2...340.2 ft/s | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD8600 | R 1 DN25 | 14...3750 l/min / 0.4...103.7 m/s / 0.8...225 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD8601 | 1" NPT DN25 | 25...7945 scfh / 0.4...132.4 scfm / 1.2...340.2 ft/s | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
SD9000 | R 1 1/2 DN40 | 20...6835 l/min / 0.3...95.3 m/s / 1.5...410 m³/h | stainless steel (1.4301 / 304); FKM; ceramics glass passivated; PEEK GF30; polyester; aluminum | PNP | normally open / closed; (configurable); analog |
SD9500 | R 1 1/2 DN40 | 20...6830 l/min / 0.3...81 m/s / 1.4...410 m³/h | stainless steel (1.4301 / 304); stainless steel (1.4305 / 303); FKM; ceramics glass passivated; PPS GF40; Al2O3 (ceramics); acrylate | PNP/NPN | normally open / closed; (configurable); analog |
