O5 distance sensors with display
The O5D is a distance sensor with time-of-flight measurement based on PMD technology (PMD = Photonic Mixer Device). It combines the advantages of long ranges, reliable background suppression, visible red light and high excess gain in one compact, rectangular standard housing. The switch point can be set to the nearest centimetre via "+/-" buttons and the display. Thanks to IO-Link, the switch point can also be set from a controller or PC. The current value can be viewed on the display at all times. The accurate background suppression ensures that even shiny, matt, dark or light objects are safely detected. The unit allows any angle of incidence and thus any mounting position, which facilitates installation and saves costs. Versions with laser class 1 meet the requirements of applications in the automotive industry.
- Precise background suppression and color-independent detection
- PMD time-of-flight measurement for very long range
- With display and pushbuttons for precise switch point setting
- Variants with laser protection class 1
- Distance shown on the integrated display
MPN | Product designation | Dimensions | Range | Range referred to prismatic reflector | Material |
---|---|---|---|---|---|
O5D100 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA | ||
O5D101 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA | ||
O5D102 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA | ||
O5D150 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA | ||
O5D151 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA | ||
O5D159 | Photoelectric distance sensor | 56 x 18.2 x 46.8 mm | housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA |
SKU | Description | List price | - |
---|---|---|---|
IFM-055040010010 | IO-Link - IO-Link position sensors - IO-Link - Inductive sensors | $0.01 | |
IFM-055040020010 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Cylindrical capacitive sensors | $0.01 | |
IFM-055040020020 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Rectangular capacitive sensors | $0.01 | |
IFM-055040020030 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Capacitive sensors with LED display | $0.01 | |
IFM-055040030010 | IO-Link - IO-Link position sensors - IO-Link - Magnetic sensors | $0.01 | |
IFM-055040050010 | IO-Link - IO-Link position sensors - IO-Link - Ultrasonic sensors | $0.01 | |
IFM-055040060010 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O6 wetline for harsh applications | $0.01 | |
IFM-055040060025 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O8 for short range precise applications | $0.01 | |
IFM-055040060030 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - Optical fork sensors | $0.01 | |
IFM-055040060040 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - provision of the distance value via IO-Link | $0.01 | |
IFM-055040090010 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors with adjustment dial | $0.01 | |
IFM-055040090020 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors for harsh environments | $0.01 | |
IFM-055040090040 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O1D laser distance sensors for industrial automation | $0.01 | |
IFM-055040090050 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - PMD Profiler for object profile checking | $0.01 | |
IFM-055040090060 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - Distance sensors type M18 Cube in metal housing | $0.01 |
