Distance sensors of type M30 with intuitive operation
The OID is a distance sensor with time-of-flight measurement based on PMD technology (PMD = Photonic Mixer Device). It combines the advantages of long ranges, reliable background suppression, visible red light and high excess gain in one compact, robust M30 housing. Switch point setting of the unit is easy and intuitive via a scaled setting ring (easy-turn). A scale shows the distance set. The switch point can thus be set before installation. The accurate background suppression ensures that even shiny, matt, dark or light objects are safely detected. The unit allows any angle of incidence and thus any mounting position, which facilitates installation and saves costs. Versions with laser class 1 meet the requirements of applications in the automotive industry.
- Very long range due to time-of-flight measurement
- Reliable background suppression and color-independent detection
- Easy parameter setting via adjustment dial
- User-friendly communication via IO-Link
- Reliable detection of glossy surfaces
| MPN | Product designation | Dimensions | Range | Range referred to prismatic reflector | Material |
|---|---|---|---|---|---|
| OID200 | Photoelectric distance sensor | M30 x 1.5 / L = 100 mm | housing: stainless steel; front lens: PMMA; LED window: PC; PBT; PC; FKM | ||
| OID201 | Photoelectric distance sensor | M30 x 1.5 / L = 100 mm | housing: stainless steel; front lens: PMMA; LED window: PC; PBT; PC; FKM | ||
| OID202 | Photoelectric distance sensor | M30 x 1.5 / L = 100 mm | housing: stainless steel; front lens: PMMA; LED window: PC; PBT; PC; FKM | ||
| OID250 | Photoelectric distance sensor | M30 x 1.5 / L = 100 mm | housing: stainless steel; front lens: PMMA; LED window: PC; PBT; PC; FKM | ||
| OID251 | Photoelectric distance sensor | M30 x 1.5 / L = 100 mm | housing: stainless steel; front lens: PMMA; LED window: PC; PBT; PC; FKM |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-055040010010 | IO-Link - IO-Link position sensors - IO-Link - Inductive sensors | $0.01 | |
| IFM-055040020010 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Cylindrical capacitive sensors | $0.01 | |
| IFM-055040020020 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Rectangular capacitive sensors | $0.01 | |
| IFM-055040020030 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Capacitive sensors with LED display | $0.01 | |
| IFM-055040030010 | IO-Link - IO-Link position sensors - IO-Link - Magnetic sensors | $0.01 | |
| IFM-055040050010 | IO-Link - IO-Link position sensors - IO-Link - Ultrasonic sensors | $0.01 | |
| IFM-055040060010 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O6 wetline for harsh applications | $0.01 | |
| IFM-055040060025 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O8 for short range precise applications | $0.01 | |
| IFM-055040060030 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - Optical fork sensors | $0.01 | |
| IFM-055040060040 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - provision of the distance value via IO-Link | $0.01 | |
| IFM-055040090020 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors for harsh environments | $0.01 | |
| IFM-055040090030 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O5D laser distance sensors with display | $0.01 | |
| IFM-055040090040 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O1D laser distance sensors for industrial automation | $0.01 | |
| IFM-055040090050 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - PMD Profiler for object profile checking | $0.01 | |
| IFM-055040090060 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - Distance sensors type M18 Cube in metal housing | $0.01 |
