Capacitive IO-Link sensors – with switch point visualisation
Capacitive sensors detect bulk materials or liquids through non-metallic vessel walls. An intuitive 12-LED bar display allows the user to adapt the switch point to suit the application conditions. Once the optimal setting is reached, the LED in the centre of the display lights. The lit green LEDs on either side of the switch point indicate the reliability of the switch point. Deposits, material changes etc. are displayed directly on the sensor and the user can readjust the switch point precisely as needed. An imminent error can be detected in good time and avoided. This minimises the risk of failures or deactivation. The parameters can either be set via the buttons on the sensor or via IO-Link interface using the USB interface E30396 or the memory plug E30398. The LINERECORDER SENSOR software is used to display the measured sensor values and set the parameters online as well as offline. Thanks to the visualisation of actual measured values tolerance limits can be defined around the set switch point.
- Use in high medium temperatures
- For position detection or level monitoring
- High protection rating for the requirements of harsh industrial environments
- Easily adjustable sensing range
- With signal display for a perfect switch point
MPN | Sensing range | Output function | Output | Dimensions | Connection |
---|---|---|---|---|---|
KI5300 | 0.5...40 mm non-flush mountable | normally open | DC NPN | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5301 | 0.5...40 mm non-flush mountable | normally closed | DC PNP | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5302 | 0.5...40 mm non-flush mountable | normally closed | DC NPN | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5303 | 0.5...40 mm non-flush mountable | normally open | DC PNP | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5304 | 0.5...40 mm quasi flush | normally closed | DC PNP | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5305 | 0.5...40 mm quasi flush | normally open | DC PNP | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI5324 | 0.5...40 mm non-flush mountable | normally open | DC PNP | M30 x 1.5 / L = 92 mm | 5 m PUR-Cable |
KI6000 | 0.5...40 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | M30 x 1.5 / L = 92 mm | M12 Connector |
KI6001 | 0.5...40 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | M30 x 1.5 / L = 92 mm | 2 m PUR-Cable |
KI6002 | 0.5...40 mm non-flush mountable | normally open / closed; (selectable) | DC PNP | M30 x 1.5 / L = 92 mm | 10 m PUR-Cable |
KI6003 | 0.5...40 mm non-flush mountable | normally open / closed; (selectable) | DC NPN | M30 x 1.5 / L = 92 mm | 10 m PUR-Cable |
SKU | Description | List price | - |
---|---|---|---|
IFM-055040010010 | IO-Link - IO-Link position sensors - IO-Link - Inductive sensors | $0.01 | |
IFM-055040020010 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Cylindrical capacitive sensors | $0.01 | |
IFM-055040020020 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Rectangular capacitive sensors | $0.01 | |
IFM-055040030010 | IO-Link - IO-Link position sensors - IO-Link - Magnetic sensors | $0.01 | |
IFM-055040050010 | IO-Link - IO-Link position sensors - IO-Link - Ultrasonic sensors | $0.01 | |
IFM-055040060010 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O6 wetline for harsh applications | $0.01 | |
IFM-055040060025 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O8 for short range precise applications | $0.01 | |
IFM-055040060030 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - Optical fork sensors | $0.01 | |
IFM-055040060040 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - provision of the distance value via IO-Link | $0.01 | |
IFM-055040090010 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors with adjustment dial | $0.01 | |
IFM-055040090020 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors for harsh environments | $0.01 | |
IFM-055040090030 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O5D laser distance sensors with display | $0.01 | |
IFM-055040090040 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O1D laser distance sensors for industrial automation | $0.01 | |
IFM-055040090050 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - PMD Profiler for object profile checking | $0.01 | |
IFM-055040090060 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - Distance sensors type M18 Cube in metal housing | $0.01 |
