Photoelectric sensors for the food industry
The photoelectric sensors of the O6 wetline series are designed for the food industry and offer an outstanding optical performance. The robust stainless steel housing with protection rating IP 68 / IP 69K is suited for use in harsh environments. The potentiometers and rotary switches are fitted with a double seal. The front pane is embedded flush and made of resistant, shatterproof plastic. This allows residue-free cleaning. The transparent black housing cover ensures that, even in bright lighting conditions, the LEDs for switching status and operation are clearly visible. The clearly defined consistent light spot ensures precise object detection. There is no scattered light which could interfere with other photoelectric sensors in close vicinity. Diffuse reflection sensors distinguish themselves by reliable background suppression, even in case of highly reflective backgrounds. The sensing range is independent of the type and colour of the object to be detected. A special feature is the automatic sensitivity compensation that ensures reliable operation even in steam, smoke or highly reflective environments.
- Very long range, independent of the object color
- Intuitive setting of sensitivity and output function
- Precise background suppression sensing on highly reflective background
- Resistant to high-pressure cleaning with aggressive cleaning agents
- Robust stainless steel housing for the requirements of the food and beverage industry
MPN | Product designation | Transmitter / receiver | Range | Range referred to prismatic reflector | Dimensions |
---|---|---|---|---|---|
O6E309 | Through-beam sensor | receiver | < 10 m | 34.8 x 13 x 21 mm | |
O6H309 | Diffuse reflection sensor | 2...200 mm | 41.3 x 13 x 21 mm | ||
O6P309 | Retro-reflective sensor | 0.05...5 | 41.3 x 13 x 21 mm | ||
O6S305 | Through-beam sensor | transmitter | < 10 m | 34.8 x 13 x 21 mm | |
O6T309 | Diffuse reflection sensor | 5...500 mm | 41.3 x 13 x 21 mm | ||
OGE381 | Through-beam sensor | receiver | < 15 m | M18 x 1 mm |
SKU | Description | List price | - |
---|---|---|---|
IFM-055040010010 | IO-Link - IO-Link position sensors - IO-Link - Inductive sensors | $0.01 | |
IFM-055040020010 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Cylindrical capacitive sensors | $0.01 | |
IFM-055040020020 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Rectangular capacitive sensors | $0.01 | |
IFM-055040020030 | IO-Link - IO-Link position sensors - IO-Link - Capacitive sensors / IO-Link - Capacitive sensors with LED display | $0.01 | |
IFM-055040030010 | IO-Link - IO-Link position sensors - IO-Link - Magnetic sensors | $0.01 | |
IFM-055040050010 | IO-Link - IO-Link position sensors - IO-Link - Ultrasonic sensors | $0.01 | |
IFM-055040060025 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - O8 for short range precise applications | $0.01 | |
IFM-055040060030 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - Optical fork sensors | $0.01 | |
IFM-055040060040 | IO-Link - IO-Link position sensors - IO-Link - Photoelectric sensors / IO-Link - provision of the distance value via IO-Link | $0.01 | |
IFM-055040090010 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors with adjustment dial | $0.01 | |
IFM-055040090020 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - OID laser distance sensors for harsh environments | $0.01 | |
IFM-055040090030 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O5D laser distance sensors with display | $0.01 | |
IFM-055040090040 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - O1D laser distance sensors for industrial automation | $0.01 | |
IFM-055040090050 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - PMD Profiler for object profile checking | $0.01 | |
IFM-055040090060 | IO-Link - IO-Link position sensors - IO-Link - Distance sensors / IO-Link - Distance sensors type M18 Cube in metal housing | $0.01 |
