Modular flow monitoring
In applications where it is not possible to use flow sensors with integrated evaluation, sensors are used in combination with evaluation units. Examples include hazardous areas, confined spaces or if flow values are to be indicated in a decentralised manner. Sensors with ceramic housing can be used in aggressive media. The product range comprises evaluation units for control cabinet installation or local mounting. Depending on the unit, it is possible to monitor flow, temperature and/or wire break. All units indicate the flow by means of an LED bar graph. The evaluation units for local mounting are connected to the flow sensor directly at the measuring point using an M12 connector. Sensors and evaluation systems are designed and approved for use in hazardous areas according to the applicable directives.
- For the connection of sensors with large immersion depths
- For sensors made of ceramics, high-grade stainless steel and titanium
- Teach button allows easy scaling of the measuring range
- Flow and switch point are indicated by LEDs directly on the unit
- Versions in AC or DCV
MPN | Installation length EL | Materials (wetted parts) | Electrical design | Process connection | Output function |
---|---|---|---|---|---|
SF0516 | stainless steel (1.4571/316Ti ) | Clamp DN25...DN40 (1...1,5") | |||
SF111A | 27 mm | stainless steel (1.4404 / 316L) | M12 x 1 | ||
SF120A | 27 mm | stainless steel (1.4404 / 316L) | M12 x 1 | ||
SF121A | 27 mm | stainless steel (1.4404 / 316L) | M12 x 1 | ||
SF211A | 27 mm | stainless steel (1.4404 / 316L) | G 1/4 external thread | ||
SF220A | 27 mm | stainless steel (1.4404 / 316L) | G 1/4 external thread | ||
SF221A | 27 mm | stainless steel (1.4404 / 316L) | G 1/4 external thread | ||
SF2405 | 27 mm | ceramics (99.7 % Al2O3) | G 1/4 external thread | ||
SF2410 | 27 mm | ceramics (99.7 % Al2O3) | G 1/4 | ||
SF311A | 45 mm | stainless steel (1.4404 / 316L) | G 1/2 external thread | ||
SF320A | 45 mm | stainless steel (1.4404 / 316L) | G 1/2 external thread | ||
SF321A | 45 mm | stainless steel (1.4404 / 316L) | G 1/2 external thread | ||
SF3405 | 45 mm | ceramics (99.7 % Al2O3) | G 1/2 external thread | ||
SF3410 | 45 mm | ceramics (99.7 % Al2O3) | G 1/2 external thread | ||
SF5200 | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5201 | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5300 | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5350 | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5700 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5701 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5702 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5703 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5704 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF5800 | titanium (3.7035); O-ring: FKM 80 Shore A | M18 x 1,5 Internal thread | |||
SF6200 | stainless steel (1.4404 / 316L) several parts, welded | Ø 10 mm | |||
SF6201 | stainless steel (1.4404 / 316L) several parts, welded | Ø 10 mm | |||
SF620A | stainless steel (1.4404 / 316L) several parts, welded | Ø 10 mm | |||
SN0150 | Relay | ||||
SN0151 | Relay | ||||
SN0152 | Relay | ||||
SN2301 | Relay | ||||
SN2302 | Relay | ||||
SP321A | stainless steel (1.4404 / 316L) | G 1/2 external thread | |||
SR0127 | PNP | ||||
SR0150 | Relay | ||||
SR0151 | Relay | ||||
SR0153 | Relay | ||||
SR2301 | Relay | ||||
SR307A | Relay | ||||
SR5900 | PNP | ||||
SR5906 | Relay |
SKU | Description | List price | - |
---|---|---|---|
IFM-040030010010 | Process Sensors - Flow - Liquids - Thermal flow switches - Type SI | $0.01 | |
IFM-040030010020 | Process Sensors - Flow - Liquids - Thermal flow switches for sanitary applications - Type SI | $0.01 | |
IFM-040030010025 | Process Sensors - Flow - Liquids - Thermal flow sensors with display - Type SA | $0.01 | |
IFM-040030010030 | Process Sensors - Flow - Liquids - Remote mount flow switches - Type SF, SN and SR | $0.01 | |
IFM-040030010040 | Process Sensors - Flow - Liquids - Flowmeters with magnetic-inductive technology - Type SM | $0.01 | |
IFM-040030010050 | Process Sensors - Flow - Liquids - Flowmeters with ultrasonic technology - Type SU | $0.01 | |
IFM-040030010060 | Process Sensors - Flow - Liquids - Mechatronic flow switches for coolants - Type SBU | $0.01 | |
IFM-040030010070 | Process Sensors - Flow - Liquids - Mechatronic flow sensors - Type SB | $0.01 | |
IFM-040030010080 | Process Sensors - Flow - Liquids - Flowmeters with display with vortex technology - Type SV | $0.01 | |
IFM-040030010085 | Process Sensors - Flow - Liquids - Vortex flowmeters - Type SV | $0.01 | |
IFM-040030010090 | Process Sensors - Flow - Liquids - Mechatronic flowmeters with display - Type SB | $0.01 | |
IFM-040030010100 | Process Sensors - Flow - Liquids - Evaluation units for flow monitoring | $0.01 | |
IFM-040030010105 | Process Sensors - Flow - Liquids - Cooling water control panels | $0.01 | |
IFM-040030020130 | Process Sensors - Flow - Gases - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
IFM-040030020150 | Process Sensors - Flow - Gases - Evaluation units for flow monitoring | $0.01 |
