Evaluation units
In some applications, it is not possible to use flow sensors with integrated evaluation, due to confined spaces or hard to reach areas. For these applications, ifm evaluation units combine with our flow monitoring sensors to provide process values. The Flow Monitoring Evaluation Unit product range from ifm includes options for control cabinet installation or local mounting. Depending on the product, it is possible to monitor flow, temperature and/or wire breaks simultaneously. Each ifm unit indicates flow on a highly visible LED bar graph. Directly connect flow monitors to the evaluation units at the point of measurement using an M12 connector when mounting locally. ifm sensors and evaluation systems are designed for flexibility so you can monitor flow values in areas that are out of reach or in confined spaces, while sending the data back to where it is best for you to access it.
- High repeatability
- Simple setting mode for quick set-up
- Variable process connection using adapters
- Reliable monitoring of liquids and gases
- Electronic locking of the setting values
| MPN | Product designation | Operating voltage | Electrical design | Protection | Temperature range |
|---|---|---|---|---|---|
| SN0150 | Control monitor for flow sensors | 90...240 AC V | Relay | IP 20 | 0...80 °C |
| SN0151 | Control monitor for flow sensors | 90...240 AC V | Relay | IP 20 | 0...80 °C |
| SN0152 | Control monitor for flow sensors | 90...240 AC V | Relay | IP 20 | 40...120 °C |
| SN2301 | Control monitor for flow sensors | < 230 AC V | Relay | IP 40 | |
| SN2302 | Control monitor for flow sensors | < 110 AC V | Relay | IP 40 | |
| SR0127 | Control monitor for flow sensors | 24 DC V | PNP | IP 50 | |
| SR0150 | Control monitor for flow sensors | 24 DC V | Relay | IP 20 | 0...80 °C |
| SR0151 | Control monitor for flow sensors | 24 DC V | Relay | IP 20 | 40...120 °C |
| SR0153 | Control monitor for flow sensors | 24 DC V | Relay | IP 20 | 0...80 °C |
| SR2301 | Control monitor for flow sensors | 24 DC V | Relay | IP 40 | |
| SR307A | Control monitor for flow sensors | 24 DC V | Relay | IP 20 | |
| SR5900 | Control monitor for flow sensors | 19...36 DC V | PNP | IP 67 | |
| SR5906 | Control monitor for flow sensors | 90...240 AC V | Relay | IP 67 |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-040030010010 | Process Sensors - Flow - Liquids - Thermal flow switches - Type SI | $0.01 | |
| IFM-040030010020 | Process Sensors - Flow - Liquids - Thermal flow switches for sanitary applications - Type SI | $0.01 | |
| IFM-040030010025 | Process Sensors - Flow - Liquids - Thermal flow sensors with display - Type SA | $0.01 | |
| IFM-040030010030 | Process Sensors - Flow - Liquids - Remote mount flow switches - Type SF, SN and SR | $0.01 | |
| IFM-040030010040 | Process Sensors - Flow - Liquids - Flowmeters with magnetic-inductive technology - Type SM | $0.01 | |
| IFM-040030010050 | Process Sensors - Flow - Liquids - Flowmeters with ultrasonic technology - Type SU | $0.01 | |
| IFM-040030010060 | Process Sensors - Flow - Liquids - Mechatronic flow switches for coolants - Type SBU | $0.01 | |
| IFM-040030010070 | Process Sensors - Flow - Liquids - Mechatronic flow sensors - Type SB | $0.01 | |
| IFM-040030010080 | Process Sensors - Flow - Liquids - Flowmeters with display with vortex technology - Type SV | $0.01 | |
| IFM-040030010085 | Process Sensors - Flow - Liquids - Vortex flowmeters - Type SV | $0.01 | |
| IFM-040030010090 | Process Sensors - Flow - Liquids - Mechatronic flowmeters with display - Type SB | $0.01 | |
| IFM-040030010105 | Process Sensors - Flow - Liquids - Cooling water control panels | $0.01 | |
| IFM-040030020120 | Process Sensors - Flow - Gases - Remote mount flow switches - Type SF, SN and SR | $0.01 | |
| IFM-040030020130 | Process Sensors - Flow - Gases - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
| IFM-040030020150 | Process Sensors - Flow - Gases - Evaluation units for flow monitoring | $0.01 |
