Headline
Compact flow sensors for hygienic areas
The flow sensors of the SI6 series serve to monitor liquids and gases in pipes in the food and beverage industry. Thanks to a broad selection of process adapters, the sensors can be used in nearly all applications. The robust stainless steel housing with protection rating IP 67 / IP 69K is suited for use in harsh environments. The sensors can be used at medium temperatures up to 120 °C. The flow range and the switch points are adjusted using a pushbutton on the unit. A multicolour LED display indicates the nominal flow range and the switch point. Electronic locking of the settings prevents unintentional maladjustment. The possibility of restoring the factory settings provides additional safety.
Features & Benefits
- Specially for the use in hygienic applications
- Suitable for medium temperatures up to 140 °C
- Clearly visible 4-digit LED display or bar graph for for indication of switch point and flow
- Extensive range of process adapters in the accessories
- Wetted parts made of stainless steel
Additional Notes
| MPN | Probe length L | Materials (wetted parts) | Electrical design | Process connection | Output function |
|---|---|---|---|---|---|
| SA4100 | 100 mm | stainless steel (1.4404 / 316L) | PNP/NPN | Diameter Ø 8 mm | normally open / closed; (configurable); analog |
| SA4104 | 100 mm | stainless steel (1.4404 / 316L) | Diameter Ø 8 mm | analog | |
| SA4110 | 100 mm | stainless steel (1.4404 / 316L) | PNP/NPN | Diameter Ø 8 mm | normally open / closed; (configurable); analog |
| SA4114 | 100 mm | stainless steel (1.4404 / 316L) | Diameter Ø 8 mm | analog | |
| SA4300 | 200 mm | stainless steel (1.4404 / 316L) | PNP/NPN | Diameter Ø 8 mm | normally open / closed; (configurable); analog |
| SA4304 | 200 mm | stainless steel (1.4404 / 316L) | Diameter Ø 8 mm | analog | |
| SA4310 | 200 mm | stainless steel (1.4404 / 316L) | PNP/NPN | Diameter Ø 8 mm | normally open / closed; (configurable); analog |
| SA4314 | 200 mm | stainless steel (1.4404 / 316L) | Diameter Ø 8 mm | analog | |
| SI6000 | 55 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | Aseptoflex | normally open / closed; (configurable) |
| SI6100 | 20 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | Aseptoflex | normally open / closed; (configurable) |
| SI6200 | 38 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | Aseptoflex | normally open / closed; (configurable) |
| SI6600 | 20 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | G 1 Aseptoflex Vario | normally open / closed; (configurable) |
| SI6700 | 38 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | G 1 Aseptoflex Vario | normally open / closed; (configurable) |
| SI6800 | 55 mm | stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4 | PNP | G 1 Aseptoflex Vario | normally open / closed; (configurable) |
