Vortex flow meters
The SV range flow sensors monitor hydrous media and reliably detect the volumetric flow quantity. For more demanding tasks, sensors which can measure both the volumetric flow quantity and the medium temperature are offered. They are frequently used in cooling circuits, e.g. in steelworks, the automotive industry and in glassmaking. The sensors operate to the vortex measuring principle. Behind a blunt body (or shedder) integrated in the measuring pipe, the flowing medium generates swirling vortices depending on the velocity. These vortices are a reliable indicator of the flow rate. The vortex principle is virtually independent of pressure and temperature fluctuations of the medium. The current flow is output as an analogue signal, the temperature as a Pt1000 signal.
- Integrated temperature measurement
- Can be used for water and water-based media, including deionized water
- Quick and easy set-up
- Compact housing for installation where space is restricted
| MPN | Measuring range | Materials (wetted parts) | Process connection | Output function |
|---|---|---|---|---|
| SV3050 | 0.5...10 l/min - 0.074...1.474 m/s | ETFE; PA 6T; FKM | G 1/2 DN6 | analog |
| SV3150 | 0.5...10 l/min - 0.074...1.474 m/s | ETFE; PA 6T; EPDM | G 1/2 DN6 | analog |
| SV4050 | 0.9...15 l/min - 0.133...2.21 m/s | ETFE; PA 6T; FKM | G 1/2 DN8 | analog |
| SV4150 | 0.9...15 l/min - 0.133...2.21 m/s | ETFE; PA 6T; EPDM | G 1/2 DN8 | analog |
| SV5050 | 1.8...32 l/min - 0.265...4.716 m/s | ETFE; PA 6T; FKM | G 3/4 DN10 | analog |
| SV5150 | 1.8...32 l/min - 0.265...4.716 m/s | ETFE; PA 6T; EPDM | G 3/4 DN10 | analog |
| SV6050 | 3.5...50 l/min - 0.29...4.145 m/s | ETFE; PA 6T; FKM | G 3/4 DN15 | analog |
| SV6150 | 3.5...50 l/min - 0.29...4.145 m/s | ETFE; PA 6T; EPDM | G 3/4 DN15 | analog |
| SV7050 | 5...85 l/min - 0.265...4.509 m/s | ETFE; PA 6T; FKM | G 1 DN20 | analog |
| SV7150 | 5...85 l/min - 0.265...4.509 m/s | ETFE; PA 6T; EPDM | G 1 DN20 | analog |
| SV8050 | 9...150 l/min - 0.283...4.709 m/s | ETFE; PA 6T; FKM | G 1 1/4 DN25 | analog |
| SV8150 | 9...150 l/min - 0.283...4.709 m/s | ETFE; PA 6T; EPDM | G 1 1/4 DN25 | analog |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-040030010010 | Process Sensors - Flow - Liquids - Thermal flow switches - Type SI | $0.01 | |
| IFM-040030010020 | Process Sensors - Flow - Liquids - Thermal flow switches for sanitary applications - Type SI | $0.01 | |
| IFM-040030010025 | Process Sensors - Flow - Liquids - Thermal flow sensors with display - Type SA | $0.01 | |
| IFM-040030010030 | Process Sensors - Flow - Liquids - Remote mount flow switches - Type SF, SN and SR | $0.01 | |
| IFM-040030010040 | Process Sensors - Flow - Liquids - Flowmeters with magnetic-inductive technology - Type SM | $0.01 | |
| IFM-040030010050 | Process Sensors - Flow - Liquids - Flowmeters with ultrasonic technology - Type SU | $0.01 | |
| IFM-040030010060 | Process Sensors - Flow - Liquids - Mechatronic flow switches for coolants - Type SBU | $0.01 | |
| IFM-040030010070 | Process Sensors - Flow - Liquids - Mechatronic flow sensors - Type SB | $0.01 | |
| IFM-040030010080 | Process Sensors - Flow - Liquids - Flowmeters with display with vortex technology - Type SV | $0.01 | |
| IFM-040030010090 | Process Sensors - Flow - Liquids - Mechatronic flowmeters with display - Type SB | $0.01 | |
| IFM-040030010100 | Process Sensors - Flow - Liquids - Evaluation units for flow monitoring | $0.01 | |
| IFM-040030010105 | Process Sensors - Flow - Liquids - Cooling water control panels | $0.01 | |
| IFM-040030020120 | Process Sensors - Flow - Gases - Remote mount flow switches - Type SF, SN and SR | $0.01 | |
| IFM-040030020130 | Process Sensors - Flow - Gases - Systems for the consumption measurement of compressed air & industrial gases | $0.01 | |
| IFM-040030020150 | Process Sensors - Flow - Gases - Evaluation units for flow monitoring | $0.01 |
