Mounting sets and fixing elements
ifm offers a complete component system of easy-to-use mounting sets that make the installation of vision sensors and backlights easier for you. The solutions consist of a clamp fastened by only one screw that keeps the sensors safely in position and guarantees free movement in all axes. Whereas the sensor mounting elements used depend on the sensor type, the clamps can be mounted in three different ways: rod mounting, free-standing mounting and fitting onto aluminium extrusions which are common in industry.
Features & Benefits
- User-firendly configuration
- Simple clamping systems for rod mounting
- Protective lens covers in plastic and glass
- Cordsets and patchcords available
Additional Notes
| MPN | Product designation | Dimensions | Material |
|---|---|---|---|
| E2D107 | Mounting set | Mounting plate: stainless steel (1.4305 / 303); Clamp: stainless steel | |
| E2D108 | Mounting set | Mounting plate: stainless steel (1.4305 / 303); Clamp: stainless steel | |
| E2D109 | Mounting set | Mounting plate: stainless steel (1.4305 / 303); Clamp: stainless steel | |
| E2D110 | Mounting set | fixture: stainless steel (1.4301 / 304); Clamp: stainless steel (1.4408) | |
| E2D111 | Mounting set | fixture: stainless steel (1.4301 / 304); Clamp: stainless steel (1.4408) | |
| E2D112 | Mounting set | fixture: stainless steel (1.4301 / 304); Clamp: stainless steel (1.4408) | |
| E2D114 | Mounting set | Ø 12 / L = 250 mm | Mounting bracket: stainless steel; Clamp: stainless steel |
| E2D115 | Mounting set | 155 x 130 x 34 mm | Mounting bracket: stainless steel; Clamp: stainless steel |
| E2D116 | Mounting set | 175 x 175 x 99 mm | Mounting bracket: stainless steel; Clamp: stainless steel |
| E2D201 | Mounting set | 61.3 x 106 x 73 mm | Mounting bracket: stainless steel; Clamp: stainless steel |
| E2D401 | Mounting bracket | 126.8 x 123.3 x 23.2 mm | fixture: metal |
| E2D402 | Mounting set | 22 x 21.5 x 22 mm | fixture: metal; End cap: plastics |
| U60042 | Mounting set | fixture: stainless steel (1.4301 / 304); Clamp: stainless steel (1.4408); Mounting rod: stainless steel (1.4571/316Ti ) |
