Headline
Connection cables for mobile cameras
The connection cables with M16 socket are used for the connection of mobile cameras with video output. Using the adapter cables, the O2M camera system can be directly connected to a graphic dialogue module with colour display and analogue interface. This makes it possible to use the dialogue module not only to display machine information but also images of up to two cameras.
Features & Benefits
- Reliable connection of mobile cameras with video output
- Gold-plated contacts
- High protection rating for the requirements of harsh industrial environments
Additional Notes
| MPN | Product designation | Connection | Cable structure | Display | Number of cores |
|---|---|---|---|---|---|
| E2M200 | Adapter cable | 0.6 m PVC-Cable; M12 / M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M201 | Adapter cable | ||||
| E2M202 | Connection cable | 3 m PVC-Cable; M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M203 | Connection cable | 5 m PVC-Cable; M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M204 | Connection cable | 11 m PVC-Cable; M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M205 | Connection cable | 16 m PVC-Cable; M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M206 | Connection cable | 21 m PVC-Cable; M16 Connector | 3 x 0,34 mm² / 1 x 0,11 mm² | 4 | |
| E2M251 | Female cordset | 3.85 m PUR-Cable; M16 Connector | 7 x 0,34 mm² | 7 | |
| E3M131 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,75 mm² | 4 | |
| E3M132 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,75 mm² | 4 | |
| E3M133 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,75 mm² | 4 |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-090050010 | Cables and Connections - Mobile vehicle - Female cordsets | $0.01 | |
| IFM-090050020 | Cables and Connections - Mobile vehicle - Patchcords for CAN bus | $0.01 | |
| IFM-090050030 | Cables and Connections - Mobile vehicle - Female cordsets for CAN bus | $0.01 | |
| IFM-090050040 | Cables and Connections - Mobile vehicle - Male cordsets for CAN bus | $0.01 | |
| IFM-090050050 | Cables and Connections - Mobile vehicle - Device connection cordsets for control systems | $0.01 | |
| IFM-090050060 | Cables and Connections - Mobile vehicle - Programming and communication cordsets | $0.01 | |
| IFM-090050090 | Cables and Connections - Mobile vehicle - Y-splitters | $0.01 |
