ClassicLine field modules with quick mounting technology
The decentralised AS-Interface I/O modules of the ClassicLine series with quick mounting technology connect binary and analogue sensors and actuators to the gateway or PLC via AS-Interface. The flat cable can be inserted from three different directions. The upper and lower parts are no longer mounted by four screws but by a slide. Quick yet very secure mounting without tools is guaranteed. Thanks to their high luminosity, the LEDs for operation, function and fault indication are particularly easy to see. The ifm product range features modules with digital and analogue inputs and outputs. Sensors and actuators are connected via proven, robust M12 connectors. Their high protection rating makes the modules ideally suited for field use in harsh industrial environments.
- Safe mounting and high protection rating
- Digital inputs and outputs
- Fast detection and processing of analog inputs
- Toolless mounting
- Three selectable directions of the flat cable mounting
| MPN | Number of digital inputs | Number of analog inputs | Sensor supply of the inputs | Number of digital outputs | Number of analog outputs |
|---|---|---|---|---|---|
| AC505A | 4 | AS-i | |||
| AC505S | AS-i | ||||
| AC506S | AS-i | ||||
| AC507S | AS-i | ||||
| AC508A | 4 | ||||
| AC508S | AUX | ||||
| AC509S | AS-i | ||||
| AC514A | 2 | AS-i | 2 | ||
| AC5200 | |||||
| AC5202 | 2 | AS-i | 2 | ||
| AC5203 | 3 | ||||
| AC5204 | 4 | AS-i | 3 | ||
| AC5205 | 4 | AS-i | |||
| AC5208 | 4 | ||||
| AC5209 | 4 | AS-i | 4 | ||
| AC5210 | 8 | AS-i | |||
| AC5211 | 2 | AS-i | 2 | ||
| AC5212 | 4 | AS-i | 4 | ||
| AC5213 | 4 | ||||
| AC5214 | 2 | AS-i | 2 | ||
| AC5215 | 4 | AS-i | |||
| AC5216 | 4 | AUX | |||
| AC5218 | 2 | ||||
| AC5222 | 2 | AS-i | |||
| AC5223 | 2 | AS-i | |||
| AC5224 | 2 | AS-i | 2 | ||
| AC5225 | AS-i | ||||
| AC5226 | 4 | AUX | |||
| AC5230 | 2 | 1 | AS-i | 1 | |
| AC5233 | 4 | ||||
| AC5234 | 2 | AS-i | 2 | ||
| AC5235 | 4 | AS-i | 4 | ||
| AC5236 | 4 | AS-i | 4 | ||
| AC5245 | 4 | AS-i | |||
| AC5274 | 4 | AS-i | 3 | ||
| AC5275 | 4 | AS-i | 4 | ||
| AC5290 | 4 | AUX | |||
| AC5291 | 4 | AS-i | |||
| AC5292 | 4 | AUX | 3 | ||
| AC5293 | 4 | AUX | 4 | ||
| AC5294 | 4 | AS-i | |||
| AC5295 | 4 | AS-i |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-050030020 | Industrial Communication - Actuator-Sensor interface I/O modules - I/O modules for field applications | $0.01 | |
| IFM-050030030 | Industrial Communication - Actuator-Sensor interface I/O modules - I/O modules for harsh environment field applications | $0.01 | |
| IFM-050030040 | Industrial Communication - Actuator-Sensor interface I/O modules - Universal modules for field applications | $0.01 | |
| IFM-050030050 | Industrial Communication - Actuator-Sensor interface I/O modules - Illuminated pushbutton modules | $0.01 | |
| IFM-050030060 | Industrial Communication - Actuator-Sensor interface I/O modules - IP69K stainless steel modules for use in high pressure cleaning applications | $0.01 | |
| IFM-050030070 | Industrial Communication - Actuator-Sensor interface I/O modules - I/O modules for control cabinet installations | $0.01 | |
| IFM-050030080 | Industrial Communication - Actuator-Sensor interface I/O modules - PCB solutions | $0.01 |
