Headline
Accessories for control systems – mounting and fixing elements for displays
ifm's product range for mounting and installation of displays and dialogue units for mobile machines includes accessories for panel and surface mounting. Mounting brackets allow horizontal, vertical or overhead installation for panel mounted devices. Using fastening clips, the displays can easily be added to a control panel. Perfectly fitting seals can be used to efficiently absorb vibration. Using the RAM mount components, the dialogue unit can be used as a firmly mounted desktop unit. Two balls allow variable orientation of the unit. The back of the unit has been prepared for fixing the mounting plate.
Features & Benefits
- For the stable and secure installation of displays and dialog units
- Robust design for use in mobile machines
- Versions for panel mounting, control panel mounting and surface mounting
- Each position possible due to free movement in all directions
- Sealings to ensure an efficient vibration absorption
Additional Notes
| MPN | Product designation | Dimensions | Thread length | Inside diameter | Material |
|---|---|---|---|---|---|
| EC0401 | Cover | 163 x 112 x 50 mm | |||
| EC0402 | Cover | 163 x 112 x 50 mm | |||
| EC0403 | Mounting frame | 87 x 12 x 87 mm | stainless steel (1.4301 / 304) | ||
| EC0404 | Mounting frame | 105 x 15.6 x 120 mm | stainless steel (1.4301 / 304) | ||
| EC0405 | RAM mount set | 197 x 93.2 x 93.2 mm | Mounting arm: aluminum black anodized; Mounting plate: aluminum black anodized; ball: rubber; display carrier: plastics black | ||
| EC0406 | RAM mount set | 197 x 131 x 116 mm | Mounting arm: aluminum black anodized; Mounting plate: aluminum black anodized; ball: rubber; display carrier: plastics black | ||
| EC0407 | display carrier | 93.2 x 93.2 x 68 mm | plastics black | ||
| EC0408 | display carrier | 116 x 131 x 69 mm | plastics black | ||
| EC0409 | Mounting plate | 38.5 x 62 x 62 mm | Mounting plate: aluminum black anodized; ball: rubber | ||
| EC0730 | Mounting frame and vibration absorber | 112 x 100 x 37.3 mm | Mounting frame: stainless steel (1.4301 / 304) | ||
| EC0731 | Mounting frame and vibration absorber | 135 x 120 x 43 mm | Mounting frame: stainless steel (1.4301 / 304) | ||
| EC0733 | Mounting frame and vibration absorber | 158 x 10 x 19 mm | Mounting frame: stainless steel (1.4301 / 304); sealing: polypropylene black | ||
| EC1300 | Mounting bracket | 132 x 82 x 21.1 mm | Mounting frame: stainless steel (1.4301 / 304) | ||
| EC1410 | Mounting plate | 56 x 62 x 62 mm | |||
| EC1411 | Mounting arm short | ||||
| EC1412 | Mounting arm standard | ||||
| EC1413 | Mounting arm long | ||||
| EC1414 | RAM mount set 1 | ||||
| EC1450 | Seal and vibration absorber | 165 x 109 x 2 mm | |||
| EC1451 | Seal and vibration absorber | 165 x 189 x 2 mm | |||
| EC1453 | Fixing set | 19 x 14 x 15 mm | |||
| EC2083 | Mounting base | ||||
| EC2110 | Mounting frame and vibration absorber | 163.5 x 210 x 50.6 mm | steel sheet | ||
| EC2115 | Seal and vibration absorber | 167 x 2 x 225 mm | TPE black | ||
| EC2117 | Installation kit | steel sheet | |||
| UCR046 | bezel mount | 16.8 x 110 x 110 mm | PC |
