Headline
Connection cables with valve plug
Connection cables with valve plug are used to connect solenoid valves to splitter boxes and modules or to dual inductive sensors for quarter-turn actuators. The robust rectangular connectors are available in the forms A, B and C.
Features & Benefits
- Reliable connection of valves in the field
- High protection rating for the requirements of harsh industrial environments
- Wide operating temperature range
- Clearly visible LED
- Robust rectangular connectors
Additional Notes
MPN | Kategorie in der Zubehörliste | Connection | Cable structure | Display | Ambient temperature |
---|---|---|---|---|---|
E10817 | Patchcords | 0.3 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (16 x Ø 0,2 mm) | Power: 1 x LED yellow | -25...90 °C |
E10818 | Patchcords | 0.6 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (16 x Ø 0,2 mm) | Power: 1 x LED yellow | -25...90 °C |
E10819 | Patchcords | 0.3 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (16 x Ø 0,2 mm) | Power: 1 x LED yellow | -25...90 °C |
E10820 | Patchcords | 0.6 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (16 x Ø 0,2 mm) | Power: 1 x LED yellow | -25...90 °C |
E10821 | Patchcords | 0.3 m PVC-Cable; M12 / valve type A DIN Connector | 2 x 0,5 mm² | -25...90 °C | |
E10844 | Patchcords | 0.3 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (16 x Ø 0,2 mm) | Power: 1 x LED yellow | -25...90 °C |
E11416 | Patchcords | 0.3 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11417 | Patchcords | 0.6 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11418 | Patchcords | 1 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11419 | Patchcords | 2 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11420 | Patchcords | 5 m PUR-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11421 | Patchcords | 0.3 m PUR-Cable; M12 / valve type B DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11422 | Patchcords | 0.6 m PUR-Cable; M12 / valve type B DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11423 | Patchcords | 1 m PUR-Cable; M12 / valve type B DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11424 | Patchcords | 2 m PUR-Cable; M12 / valve type B DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11425 | Patchcords | 5 m PUR-Cable; M12 / valve type B DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11426 | Patchcords | 0.3 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11427 | Patchcords | 0.6 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11428 | Patchcords | 1 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11429 | Patchcords | 2 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11430 | Patchcords | 5 m PUR-Cable; M12 / valve type C DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED yellow | -25...80 °C |
E11431 | Patchcords | 0.3 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11432 | Patchcords | 0.6 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11433 | Patchcords | 1 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11434 | Patchcords | 2 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11435 | Patchcords | 5 m PUR-Cable; M12 / valve type B industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11436 | Patchcords | 0.3 m PUR-Cable; M12 / valve type C industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11437 | Patchcords | 0.6 m PUR-Cable; M12 / valve type C industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11438 | Patchcords | 1 m PUR-Cable; M12 / valve type C industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11439 | Patchcords | 2 m PUR-Cable; M12 / valve type C industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E11440 | Patchcords | 5 m PUR-Cable; M12 / valve type C industrial standard Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow | -25...80 °C |
E70350 | Patchcords | 2 m PUR / PVC-Cable; M12 / valve type A DIN Connector | 3 x 0,5 mm² (42 x Ø 0,1 mm) | Power: 1 x LED green | -25...90 °C |
EC2088 | Patchcords |
