Spare Parts Accessories IFM-110180050

Pictures may not be actual SKU

ifm Accessories - for control systems - Patchcables for CAN bus

Name: ifm Accessories - for control systems - Patchcables for CAN bus
Brand: ifm
SKU: IFM-110180050
Availability: InStock

IFM | ifm

110 | Accessories

ifm Accessories - for control systems

IFM-110180050

Description

IFM's 110.180.050 group of Accessories - Accessories for control systems - Patchcables for CAN bus

Base Model

Collection

110

Group

180

Options

050

Additional Options

Available to Order

Ships from PA

Typically ships within [ 2 ] days

24/7 Sales & Support 484-544-0506

Quantity:

− +

Get a Quote

Overview
SKU List

Headline

Jumper cables for CAN bus

The CAN bus M12 jumper cables ensure reliable connection of all CAN bus participants. Thanks to their high protection rating and extended temperature range, these cables are ideal for use in mobile machines. The screened and twisted PUR cable is available in various lengths.

Features & Benefits

Reliable connection technology for CAN bus participants
High protection rating for the requirements of harsh industrial environments
Wide operating temperature range
Shielded PUR cable

Additional Notes

MPN	Kategorie in der Zubehörliste	Connection	Cable structure	Ambient temperature
E11591	Patchcords	0.3 m PUR-Cable; M12 Connector	2 x 0,25 mm² (19 x Ø 0,13 mm) / 2 x 0,34 mm² (19 x Ø 0,16 mm) / 1 x 0,34 mm² (19 x Ø 0,16 mm)	-20...80 °C
E11592	Patchcords	1 m PUR-Cable; M12 Connector	2 x 0,25 mm² (19 x Ø 0,13 mm) / 2 x 0,34 mm² (19 x Ø 0,16 mm) / 1 x 0,34 mm² (19 x Ø 0,16 mm)	-25...80 °C
E11593	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,25 mm² (19 x Ø 0,13 mm) / 2 x 0,34 mm² (19 x Ø 0,16 mm) / 1 x 0,34 mm² (19 x Ø 0,16 mm)	-25...80 °C
E11594	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,25 mm² (19 x Ø 0,13 mm) / 2 x 0,34 mm² (19 x Ø 0,16 mm) / 1 x 0,34 mm² (19 x Ø 0,16 mm)	-25...80 °C
E11595	Patchcords	10 m PUR-Cable; M12 Connector	2 x 0,25 mm² (19 x Ø 0,13 mm) / 2 x 0,34 mm² (19 x Ø 0,16 mm) / 1 x 0,34 mm² (19 x Ø 0,16 mm)	-25...80 °C
E12316	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,25 mm²	-40...70 °C
E12317	Patchcords	10 m PUR-Cable; M12 Connector	2 x 0,25 mm²	-40...70 °C
E43332	Patchcords	0.15 m PUR / PVC-Cable; M12 Connector	4 x 0,25 mm²	-30...80 °C
EVC947	Patchcords	1 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC948	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC949	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC950	Patchcords	1 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC951	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC952	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC953	Patchcords	1 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC954	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC955	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC956	Patchcords	10 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC962	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC963	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC964	Patchcords	10 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC965	Patchcords	2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC966	Patchcords	5 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVC967	Patchcords	10 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVCA07	Patchcords	0.3 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
EVCA08	Patchcords	0.2 m PUR-Cable; M12 Connector	2 x 0,75 mm² (42 x Ø 0,15 mm) / 2 x 0,5 mm² (19 x Ø 0,19 mm) / 1 x 0,75 mm² (42 x Ø 0,15 mm)	-25...80 °C
