Headline
Clamp holders
Clamp holders have a fixed stop for accurate placement and allow quick and easy replacement of cylinder type sensors without having to realign. The robust housing provides protection against damage even in harsh industrial environments.
Features & Benefits
- End stop for defined installation position
- For mounting cylindrical sensors
- Easy and quick replacement without readjustment
- Reliable protection against damage
- Robust design for use in harsh industrial environments
Additional Notes
| MPN | Product designation | Design | Material |
|---|---|---|---|
| E11114 | Mounting sleeve | with end stop / M16 x 1 - Ø 12 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E11115 | Mounting sleeve | with end stop / M22 x 1 - Ø 18 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10848 | Mounting sleeve | with end stop / M12 x 1 - Ø 8 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10741 | Mounting sleeve | with end stop / M16 x 1 - Ø 12 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10806 | Mounting sleeve | with end stop / M16 x 1 - Ø 12 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10807 | Mounting sleeve | with end stop / M24 x 1,5 - Ø 18 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E12452 | Mounting sleeve | with end stop / M16 x 1 - Ø 12 mm | brass weld coated; Nuts: brass weld coated |
| E10808 | Mounting sleeve | with end stop / M36 x 1,5 - Ø 30 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10849 | Mounting sleeve | with end stop / M12 x 1 - Ø 8 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E10742 | Mounting sleeve | with end stop / M24 x 1,5 - Ø 18 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E12453 | Mounting sleeve | with end stop / M22 x 1 - Ø 18 mm | brass weld coated; Nuts: brass weld coated |
| E10743 | Mounting sleeve | with end stop / M36 x 1,5 - Ø 30 mm | brass white bronze coated; Nuts: brass white bronze coated |
| E12454 | Mounting sleeve | with end stop / M36 x 1.5 - Ø 30 mm | brass weld coated; Nuts: brass weld coated |
| E11514 | Mounting sleeve | with end stop / M22 x 1 - Ø 18 mm | steel (1.0711 / 9 S20) galvanized; Nuts: steel galvanized |
| E11513 | Mounting sleeve | with knurled nut, with end stop / M16 x 1 - Ø 12 mm | steel (1.0711 / 9 S20) galvanized; Nuts: steel galvanized |
| U20310 | Mounting sleeve | with end stop / M22 x 1 - Ø 18 mm | brass white bronze coated |
