Headline
Compact speed monitors of the DI series
In many industrial applications drives need to be monitored for rotational speed or standstill. In the automotive, food, beverage, steel and mining industries, speed sensors are used to reliably detect standstill, overspeed and underspeed of drives or belt break on conveyors. The compact speed monitors of the DI series integrate rotational speed detection and monitoring in one unit. The sensor head operates on the inductive sensing principle. The sensor detects metal actuating surfaces on rotating machine parts, e.g. on toothed wheels or camshafts. The integrated evaluation converts this information into rotational speed.Parameters are set via IO-Link.
Features & Benefits
- 2 in 1: speed sensor and evaluation in one compact housing
- Space-saving design
- Reduced installation complexity
- Easy parameter setting via IO-Link
- For direct connection to a PLC
Additional Notes
| MPN | Setting range | Dimensions | Sensing range | Nominal voltage | Electrical design |
|---|---|---|---|---|---|
| DI5026 | 5...3600 Imp/min | M30 x 1.5 / L = 80 mm | 10 mm flush mountable | 10...36 DC V | PNP/NPN |
| DI5027 | 5...24000 Imp/min | M12 x 1 / L = 60 mm | 3.5 mm flush mountable | 10...30 DC V | PNP/NPN |
| DI5028 | 5...24000 Imp/min | M12 x 1 / L = 60 mm | 6.5 mm non-flush mountable | 10...30 DC V | PNP/NPN |
| DI5029 | 5...24000 Imp/min | M18 x 1 / L = 60 mm | 7 mm flush mountable | 10...30 DC V | PNP/NPN |
| DI5030 | 5...24000 Imp/min | M18 x 1 / L = 60 mm | 12 mm non-flush mountable | 10...30 DC V | PNP/NPN |
| DI5031 | 5...14400 Imp/min | M30 x 1.5 / L = 65 mm | 12 mm flush mountable | 10...30 DC V | PNP/NPN |
| DI5032 | 5...14400 Imp/min | M30 x 1.5 / L = 65 mm | 21 mm non-flush mountable | 10...30 DC V | PNP/NPN |
| DI5033 | 5...9600 Imp/min | 40 x 40 x 54 mm | 20 mm flush mountable | 10...30 DC V | PNP/NPN |
| DI5034 | 5...9600 Imp/min | 40 x 40 x 54 mm | 24 mm non-flush mountable | 10...30 DC V | PNP/NPN |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-055050010010 | IO-Link - IO-Link sensors for motion control - IO-Link - Encoders / IO-Link - Incremental encoders | $0.01 | |
| IFM-055050010020 | IO-Link - IO-Link sensors for motion control - IO-Link - Encoders / IO-Link - Incremental encoders with display | $0.01 | |
| IFM-055050010030 | IO-Link - IO-Link sensors for motion control - IO-Link - Encoders / IO-Link - Multiturn encoders | $0.01 | |
| IFM-055050030010 | IO-Link - IO-Link sensors for motion control - IO-Link - Inclination sensors / IO-Link - Inclination sensors | $0.01 |
