Incremental encoders
Incremental encoders generate a precisely defined number of pulses per revolution. They are a measure of the angular or linear distance moved. The phase difference between the signals A and B, which are shifted by 90°, allows evaluation of the direction of rotation.
Features & Benefits
- Defined pulse sequence for the reliable detection of rotational speeds
- For precise position determination and linear measurement
- User-friendly communication and parameterization via IO-Link
- High shock and vibration resistance
- Hollow shaft encoder for direct mounting on actuators
Additional Notes
| MPN | Dimensions | Shaft design | Shaft diameter | Resolution | Electrical design |
|---|---|---|---|---|---|
| RA3100 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3101 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3103 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 10 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3104 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3110 | Ø 42 / L = 79.5 mm | hollow shaft open to one side | 12 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3500 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RA3501 | Ø 36.5 / L = 58.5 mm | hollow shaft open to one side | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RB3100 | Ø 36.5 / L = 65 mm | solid shaft | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RB3500 | Ø 36.5 / L = 65 mm | solid shaft | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RMU100 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 8192 steps; 16 revolutions; 13 bit | |
| RMU200 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 8192 steps; 16 revolutions; 13 bit | |
| RMU400 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 4096 steps; 4096 revolutions | |
| RO3100 | Ø 58.5 / L = 69 mm | hollow shaft open to one side | 12 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3101 | Ø 58.5 / L = 69 mm | hollow shaft open to one side | 12 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3102 | Ø 58.5 / L = 69 mm | hollow shaft open to one side | 15 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3103 | Ø 58.5 / L = 69 mm | hollow shaft open to one side | 9.525 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3104 | Ø 58.5 / L = 69 mm | hollow shaft open to one side | 15.875 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3110 | Ø 58.5 mm | hollow shaft open to one side | 15 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3500 | Ø 58.5 / L = 68.6 mm | hollow shaft open to one side | 12 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RO3501 | Ø 58.5 / L = 68.6 mm | hollow shaft open to one side | 12 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RU3100 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RU3110 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RU3500 | Ø 58 / L = 63.5 mm | solid shaft | 6 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RV3100 | Ø 58 / L = 79.5 mm | solid shaft | 10 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RV3110 | Ø 58 / L = 79.5 mm | solid shaft | 10 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
| RV3500 | Ø 58 / L = 79.5 mm | solid shaft | 10 mm | 1...10000; (configurable; Factory setting: 1024) resolution | HTL/TTL |
