AS-Interface gateways
ifm gateways establish a connection between AS-i and common fieldbus systems such as EtherNet/IP, Profibus, Profinet or EtherCAT. They control the data exchange to the sensor/actuator level and communicate rapidly with the superior control level. Thanks to the colour display, the status of all AS-i slaves is recognizable at a single glance. Sensor/actuator data can also be visualised via the integrated WEB server. The quick set-up menu and intuitive handling facilitate configuration, set-up and diagnosis. In addition, the web interface allows full remote access. The units can be operated via AS-i power supplies, DC power supplies, or a combination of both. It is also possible to supply several AS-i networks via a single power supply.
- With integrated fieldbus interface
- Reliable and fast data exchange with the sensor actuator level
- Color display for indicating the status of all AS-i slaves
- User-friendly and simple configuration, set-up and diagnosis
- Quick-setup menu with intuitive operation
MPN | Product designation | Number of AS-i masters | AS-i profile | Voltage supply | Communication interface |
---|---|---|---|---|---|
AC1375 | SmartLink DP | 1 | M4 | PROFIBUS, Profibus DP | |
AC1376 | AS-i PROFIBUS DP gateway | 2 | M4 | PROFIBUS, Profibus DP | |
AC1401 | AS-i PROFINET gateway | 1 | M4 | PROFINET, UDP/IP, Modbus TCP, TCP/IP | |
AC1402 | AS-i PROFINET gateway | 2 | M4 | PROFINET, UDP/IP, Modbus TCP, TCP/IP | |
AC1411 | AS-i PROFIBUS gateway | 1 | M4 | PROFIBUS, Profibus DP, UDP/IP, Modbus TCP, TCP/IP | |
AC1412 | AS-i PROFIBUS gateway | 2 | M4 | PROFIBUS, Profibus DP, UDP/IP, Modbus TCP, TCP/IP | |
AC1421 | AS-i EtherNet/IP gateway | 1 | M4 | UDP/IP, Modbus TCP, TCP/IP, EtherNet/IP | |
AC1422 | AS-i EtherNet/IP gateway | 2 | M4 | UDP/IP, Modbus TCP, TCP/IP, EtherNet/IP |
SKU | Description | List price | - |
---|---|---|---|
IFM-050072020 | Industrial Communication - Fieldbus components - AS-i gateways with PLC functionality | $0.01 | |
IFM-050072030 | Industrial Communication - Fieldbus components - AS-i gateways with fail-safe PLC | $0.01 | |
IFM-050072040 | Industrial Communication - Fieldbus components - IO-Link - DIN rail mountable masters for control cabinets | $0.01 | |
IFM-050072050 | Industrial Communication - Fieldbus components - IO-Link - Field mountable masters for industrial automation | $0.01 | |
IFM-050072055 | Industrial Communication - Fieldbus components - IO-Link - Field mountable masters for high pressure cleaning | $0.01 | |
IFM-050072060 | Industrial Communication - Fieldbus components - RFID 125 kHz - Evaluation systems | $0.01 | |
IFM-050072070 | Industrial Communication - Fieldbus components - RFID 13.56 MHz - Evaluation systems | $0.01 | |
IFM-050072080 | Industrial Communication - Fieldbus components - RFID UHF - Readers | $0.01 | |
IFM-050072090 | Industrial Communication - Fieldbus components - Absolute singleturn encoders | $0.01 | |
IFM-050072100 | Industrial Communication - Fieldbus components - Absolute multiturn encoders | $0.01 |
