RFID read/write heads
The RF identification system DTS125 enables non-contact reading from and/or writing to RFID transponders (ID tags). The compact read/write heads include, in addition to the antenna, the complete evaluation and the interface to AS-Interface. So the units can be operated directly in the AS-i network. The data is converted into digitally coded values and provided to the AS-i control level without further programming. Applications are found in production lines, where the units are used for material flow control. In rail-borne conveyor systems, code carriers (ID tags) are attached to the containers, goods carriers or workpiece carriers to be identified. When they enter the detection zone of the read/write heads, the data is read. Up to 31 devices can be controlled by an AS-i master. The product range comprises read/write heads for detection zones of different sizes and a large variety of ID tags.
- RFID for track and trace applications
- Simple and quick set-up
- Connection of up to 31 RFID readers to one AS-i master
- High reading reliability
| MPN | Product designation | Operating frequency | Communication interface | Dimensions | Memory size |
|---|---|---|---|---|---|
| DTA100 | Read/write antenna | 0,125 MHz | AS-i | 55 x 24 x 41 mm | |
| DTA101 | Read head | 0,125 MHz | AS-i | 55 x 24 x 41 mm | |
| DTA200 | Read/write antenna | 0,125 MHz | AS-i | 40 x 40 x 54 mm | |
| DTA201 | Read head | 0,125 MHz | AS-i | 40 x 40 x 54 mm | |
| DTA300 | Read/write antenna | 0,125 MHz | AS-i | 92 x 80 x 40 mm | |
| DTA301 | Read head | 0,125 MHz | AS-i | 92 x 80 x 40 mm |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-050040010 | Industrial Communication - Actuator-Sensor interface systems and sensors - Airboxes for pneumatic applications | $0.01 | |
| IFM-050040020 | Industrial Communication - Actuator-Sensor interface systems and sensors - Dual inductive sensors for quarter-turn actuator feedback | $0.01 | |
| IFM-050040025 | Industrial Communication - Actuator-Sensor interface systems and sensors - Automation kit for valve actuators | $0.01 | |
| IFM-050040030 | Industrial Communication - Actuator-Sensor interface systems and sensors - Valve sensors for rising stem valves | $0.01 | |
| IFM-050040040 | Industrial Communication - Actuator-Sensor interface systems and sensors - Inductive sensors for coolant applications | $0.01 | |
| IFM-050040050 | Industrial Communication - Actuator-Sensor interface systems and sensors - Temperature sensors | $0.01 |
