Inductive sensors for machine tools
Inductive sensors with AS-Interface have been specially developed for metalworking applications. Oils and coolants heavily impact the machine components installed in machine tools. Standard sensors are insufficient in many applications. The C series has been specially designed for this industry segment. The sealing concept of the sensors combined with the suitable ecolink connector ensures maximum protection against malfunctions. The threaded body and the sensing face of the one-piece housing of the full-metal sensors are made of high-grade stainless steel. The robust material is corrosion-resistant and allows installation of the sensors in extreme applications. The AS-i interface allows the sensors to be directly integrated into AS-i networks without using additional modules. The diagnostic function can be used to check whether a target is in the certain or uncertain range.
- High protection rating for the requirements of harsh industrial environments
- Resistant to aggressive oils and coolants
- Up to 62 sensors can be connected per master
- Long sensing range minimizes physical damage
- High shock and vibration resistance
| MPN | Sensing range | Switching frequency AC | Switching frequency | Output function | Ambient temperature |
|---|---|---|---|---|---|
| IFC247 | 4 mm | 100 Hz | -25...70 °C | ||
| IFC248 | 7 mm | 100 Hz | -25...70 °C | ||
| IGC234 | 8 mm | 100 Hz | -25...70 °C | ||
| IGC235 | 12 mm | 100 Hz | -25...70 °C | ||
| IIC220 | 14 mm | 100 Hz | -25...70 °C | ||
| IIC221 | 22 mm | 100 Hz | -25...70 °C | ||
| IM5118 | 15 mm | 100 Hz | -25...70 °C |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-050040010 | Industrial Communication - Actuator-Sensor interface systems and sensors - Airboxes for pneumatic applications | $0.01 | |
| IFM-050040020 | Industrial Communication - Actuator-Sensor interface systems and sensors - Dual inductive sensors for quarter-turn actuator feedback | $0.01 | |
| IFM-050040025 | Industrial Communication - Actuator-Sensor interface systems and sensors - Automation kit for valve actuators | $0.01 | |
| IFM-050040030 | Industrial Communication - Actuator-Sensor interface systems and sensors - Valve sensors for rising stem valves | $0.01 | |
| IFM-050040050 | Industrial Communication - Actuator-Sensor interface systems and sensors - Temperature sensors | $0.01 | |
| IFM-050040060 | Industrial Communication - Actuator-Sensor interface systems and sensors - RFID read/write antennas | $0.01 |
