AirBoxes for pneumatics
The AS-i AirBox is a combination of an I/O module and a solenoid valve. In pneumatic applications, it is used for decentralised control of cylinders or valves, flaps and slides actuated by valve actuators. The AirBox can be mounted onto the AS-i flat cable without any tools, considerably reducing installation and wiring complexity. The decentralised application near the actuator increases energy efficiency. The product range includes AirBoxes with different valve functions. The AirBox in 2 x 3/2-way design is an excellent choice for the connection of two single-acting cylinders. In the event of compressed air failure these cylinders go into a safe position. The 5/2-way AirBoxes (monostable/bistable) and the 5/3-way AirBoxes are used with double-acting actuators. This valve function prevents, for example, dropping of a load in the event of compressed air failure due to the blocked middle position.
- Safe mounting and high protection rating
- Slide valves free from overlapping
- Press spike resistance up to 12 bar
- Three selectable directions of the flat cable mounting
- Extended addressing mode
| MPN | Type of mounting | Sensor supply of the inputs | Pneumatic system | Exhaust | Extended addressing mode |
|---|---|---|---|---|---|
| AC2024 | screw mounting | AS-i | 2 x 3/2-way seat valves | integrated exhaust | no |
| AC2027 | screw mounting | AS-i | 2 x 3/2-way seat valves | exhaust can be discharged through tube connection | no |
| AC2041 | screw mounting | AS-i | 2 x 3/2-way seat valves | integrated exhaust | no |
| AC2042 | screw mounting | AS-i | 2 x 3/2-way seat valves | integrated exhaust | no |
| AC2046 | screw mounting | AS-i | 1 x 4/2-way seat valve | integrated exhaust | no |
| AC2048 | screw mounting | AS-i | 1 x 4/2-way seat valve | integrated exhaust | no |
| AC2055 | screw mounting | AS-i | 2 x 3/2-way seat valves | exhaust can be discharged through tube connection | no |
| AC2057 | screw mounting | AS-i | 1 x 4/2-way seat valve | exhaust can be discharged through tube connection | no |
| AC5227 | quick mounting | AS-i | 2 x 3/2-way slide valves (free from overlapping) | exhaust can be discharged through tube connection | no |
| AC5228 | quick mounting | AS-i | 2 x 3/2-way slide valves (free from overlapping) | exhaust can be discharged through tube connection | yes |
| AC5243 | quick mounting | AS-i | 2 x 3/2-way slide valves (free from overlapping) | exhaust can be discharged through tube connection | yes |
| AC5246 | quick mounting | AS-i | 1 x 5/2-way slide valve (free from overlapping) | exhaust can be discharged through tube connection | yes |
| AC5249 | quick mounting | AS-i | 1 x 5/2-way slide valve (free from overlapping) | exhaust can be discharged through tube connection | yes |
| AC5250 | quick mounting | AS-i | 1 x 5/2-way slide valve (free from overlapping); bistable | exhaust can be discharged through tube connection | no |
| AC5251 | quick mounting | AS-i | 1 x 5/2-way slide valve (free from overlapping); bistable | exhaust can be discharged through tube connection | yes |
| AC5253 | quick mounting | AS-i | 1 x 5/2-way slide valve (free from overlapping); bistable | exhaust can be discharged through tube connection | yes |
| AC5270 | quick mounting | AS-i | 1 x 5/3-way slide valve (free from overlapping); middle position blocked | exhaust can be discharged through tube connection | yes |
| AC5271 | quick mounting | AS-i | 1 x 5/3-way slide valve (free from overlapping); middle position blocked | exhaust can be discharged through tube connection | yes |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-050040020 | Industrial Communication - Actuator-Sensor interface systems and sensors - Dual inductive sensors for quarter-turn actuator feedback | $0.01 | |
| IFM-050040025 | Industrial Communication - Actuator-Sensor interface systems and sensors - Automation kit for valve actuators | $0.01 | |
| IFM-050040030 | Industrial Communication - Actuator-Sensor interface systems and sensors - Valve sensors for rising stem valves | $0.01 | |
| IFM-050040040 | Industrial Communication - Actuator-Sensor interface systems and sensors - Inductive sensors for coolant applications | $0.01 | |
| IFM-050040050 | Industrial Communication - Actuator-Sensor interface systems and sensors - Temperature sensors | $0.01 | |
| IFM-050040060 | Industrial Communication - Actuator-Sensor interface systems and sensors - RFID read/write antennas | $0.01 |
