Absolute multiturn encoders
Absolute encoders provide an absolute numerical value for each angular position even over several revolutions. Multiturn encoders, however, do not only detect absolute angular positions but also count revolutions. Even after a voltage failure and system restart, the current position is quickly and reliably detected. The signals are output via an SSI interface or a fieldbus interface such as CAN or Profibus. ifm offers IO-Link enabled encoders to provide diagnostic information and easy integration into your controls architecture.
Features & Benefits
- Easy wiring and programming
- Versions with connector, cable or bus cap connection
- Versions as solid shaft with clamp/synchro flange or as hollow shaft
- Large variety of interfaces: SSI, PROFIBUS, PROFINET, CANopen or DeviceNet
Additional Notes
| MPN | Function principle | Dimensions | Shaft design | Shaft diameter | Resolution |
|---|---|---|---|---|---|
| RM3006 | absolute | Ø 58 / L = 94 mm | solid shaft | 6 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM3007 | absolute | Ø 58 / L = 110 mm | solid shaft | 10 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM3008 | absolute | Ø 58.5 / L = 99 mm | hollow shaft open to one side | 12 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM3011 | absolute | Ø 58 / L = 110 mm | solid shaft | 10 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM7011 | absolute | Ø 58 / L = 94 mm | solid shaft | 6 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM7012 | absolute | Ø 58 / L = 110 mm | solid shaft | 10 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM7013 | absolute | Ø 58 / L = 110 mm | solid shaft | 10 mm | 8192 steps; 4096 revolutions; 25 bit |
| RM8001 | absolute | Ø 36.5 / L = 69.5 mm | solid shaft | 6 mm | 4096 resolution; 8192 revolutions; 25 bit |
| RM8002 | absolute | Ø 36.5 / L = 79 mm | solid shaft | 10 mm | 4096 resolution; 8192 revolutions; 25 bit |
| RM8003 | absolute | Ø 36.5 / L = 67 mm | hollow shaft open to one side | 12 mm | 4096 resolution; 4096 revolutions; 24 bit |
| RM8004 | absolute | Ø 36.5 / L = 74 mm | hollow shaft open to one side | 12 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM8006 | absolute | Ø 36.5 / L = 69.5 mm | solid shaft | 10 mm | 4096 resolution; 8192 revolutions; 25 bit |
| RM8007 | absolute | Ø 36.5 / L = 74 mm | hollow shaft open to one side | 12 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9000 | absolute | Ø 36.5 / L = 100 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9001 | absolute | Ø 36.5 / L = 100 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9003 | absolute | Ø 36.5 / L = 100 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9004 | absolute | Ø 36.5 / L = 100 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9006 | absolute | Ø 36.8 / L = 76 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9007 | absolute | Ø 36.5 / L = 39 mm | solid shaft | 6 mm | 4096 steps; 4096 revolutions; 24 bit |
| RM9010 | absolute | Ø 42 / L = 107.9 mm | solid shaft | 10 mm | 4096 steps; 4096 revolutions; 24 bit |
| RMA300 | absolute | Ø 36 / L = 54.2 mm | hollow shaft open to one side | 12 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMA310 | absolute | Ø 42 / L = 89.5 mm | hollow shaft open to one side | 12 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMB300 | absolute | Ø 36 / L = 65 mm | solid shaft | 6 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMB310 | absolute | Ø 42 / L = 107.9 mm | solid shaft | 10 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMO300 | absolute | Ø 58 / L = 69 mm | hollow shaft open to one side | 15 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMS001 | absolute | 8192 steps; 16 revolutions; 17 bit | |||
| RMS002 | absolute | 8192 steps; 16 revolutions; 17 bit | |||
| RMS005 | absolute | 4096 steps; 4096 revolutions; 24 bit | |||
| RMU300 | absolute | Ø 58 / L = 79 mm | solid shaft | 6 mm | 65536 steps; 32768 revolutions; 31 bit |
| RMV300 | absolute | Ø 58 / L = 79 mm | solid shaft | 10 mm | 65536 steps; 32768 revolutions; 31 bit |
