Headline
High-resolution colour sensors
In highly automated industrial processes the colour is often a selection criterion for detecting, sorting or inspecting various products and goods. Both the colour of a product itself and the packaging, labels or imprints can be precisely detected using electronic colour sensors.
The sensor is set to the colour to be detected with one push of the button. Reliable differentiation of even the finest shades of colour is accomplished by means of five tolerance steps. The autodetect output stage automatically sets the switching output of the sensor to PNP or NPN operation.
Features & Benefits
- Recognition, sorting and checking of objects based on their color
- Setting process saves time and cost during set-up
- Reliable detection of color shades
- High switching frequency for fast processes
- Extensive range of system components for easy and secure mounting
Additional Notes
| MPN | Product designation | Range | Dimensions | Output function | Switching frequency |
|---|---|---|---|---|---|
| O5C500 | Color sensor | 15...19 mm | 56 x 18.2 x 46.8 mm | light-on/dark-on mode; (programmable) | 2000 Hz |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010090020 | Position Sensors - Application specific - Contrast sensors - Type O5K | $0.01 | |
| IFM-010090030 | Position Sensors - Application specific - Clear object detection sensors - Type O5G and OJ | $0.01 | |
| IFM-010090040 | Position Sensors - Application specific - Laser distance sensors for non-contact measurement - Type O1D | $0.01 |
