Distance sensors of type O5 with display
The O5D is a distance sensor with time-of-flight measurement based on PMD technology (PMD = Photonic Mixer Device). It combines the advantages of long ranges, reliable background suppression, visible red light and high excess gain in one compact, rectangular standard housing.
The switch point can be set to the nearest centimetre via "+/-" buttons and the display. Thanks to IO-Link, the switch point can also be set from a controller or PC. The current value can be viewed on the display at all times.
The accurate background suppression ensures that even shiny, matt, dark or light objects are safely detected. The unit allows any angle of incidence and thus any mounting position, which facilitates installation and saves costs.
Versions with laser class 1 meet the requirements of applications in the automotive industry.
- Reliable background suppression and color-independent detection
- Time-of-flight measurement in compact design
- Reliable detection of glossy surfaces
- Oblique angle to the object possible
- With display and pushbuttons for precise switch point setting
| MPN | Product designation | Measuring range | Dimensions | Output function | Laser protection class |
|---|---|---|---|---|---|
| O5D100 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 2 |
| O5D101 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 2 |
| O5D102 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 2 |
| O5D150 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 1 |
| O5D151 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 1 |
| O5D159 | Photoelectric distance sensor | 0.03...2 m | 56 x 18.2 x 46.8 mm | normally open / closed; (complementary) | 1 |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010075010 | Position Sensors - Distance - O1D laser distance sensors for industrial automation | $0.01 | |
| IFM-010075020 | Position Sensors - Distance - O1D retroreflective laser distance sensors for long range applications | $0.01 | |
| IFM-010075030 | Position Sensors - Distance - OID laser distance sensors with adjustment dial | $0.01 | |
| IFM-010075040 | Position Sensors - Distance - OID laser distance sensors for harsh environments | $0.01 | |
| IFM-010075060 | Position Sensors - Distance - Cooling boxes and protective housings for O1D distance sensors | $0.01 | |
| IFM-010075070 | Position Sensors - Distance - OGD precision distance sensor for error proofing applications | $0.01 | |
| IFM-010075080 | Position Sensors - Distance - Distance sensors - PMD Profiler for object profile checking | $0.01 |
