O1D distance sensors
The O1D is a distance sensor with time-of-flight measurement based on PMD technology (PMD = Photonic Mixer Device). Measuring only 42 x 42 x 52mm, the sensor offers a very long range, reliable background suppression, a visible red laser light spot and a high excess gain.
The sensor is resistant to extraneous light and can be used in workshops where daylight hits the sensor or object from above. Reflective objects such as metal surfaces are reliably detected; reflective strips on high-vis vests reliably suppressed. With O1D, distances can also be measured reliably when the light beam does not hit the object surface vertically. This allows flexible mounting, facilitates installation and saves costs. The accurate background suppression ensures that even shiny, matt, dark or light objects are safely detected.
The O1D distance sensor is designed for positioning, speed control and level monitoring tasks. For example, it can be used to protect autonomous industrial transport systems against collision or position industrial trucks in high rack storage areas.
Versions with laser class 1 meet the requirements of applications in the automotive industry.
- Reliable optical distance measurement with long ranges up to 10 m
- Two switching outputs, one of them programmable as analog output
- Scalable measuring range and window function
- Use in applications with background suppression
- Excellent price/performance ratio
| MPN | Product designation | Measuring range | Dimensions | Output function | Laser protection class |
|---|---|---|---|---|---|
| O1D100 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (configurable); analog | 2 |
| O1D101 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable) | 2 |
| O1D102 | Photoelectric distance sensor | 0.2...3.5 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D103 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D104 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable) | 2 |
| O1D105 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D106 | Photoelectric distance sensor | 1...75 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D108 | Photoelectric distance sensor | 0.2...18 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D120 | Photoelectric distance sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D155 | Photoelectric distance sensor | 0.3...6 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 1 |
| O1D209 | Photoelectric distance sensor | 1...100 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| O1D300 | Optical level sensor | 0.2...10 m | 59 x 42 x 52 mm | normally open / closed; (programmable); analog | 2 |
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010075020 | Position Sensors - Distance - O1D retroreflective laser distance sensors for long range applications | $0.01 | |
| IFM-010075030 | Position Sensors - Distance - OID laser distance sensors with adjustment dial | $0.01 | |
| IFM-010075040 | Position Sensors - Distance - OID laser distance sensors for harsh environments | $0.01 | |
| IFM-010075050 | Position Sensors - Distance - O5D laser distance sensors with display | $0.01 | |
| IFM-010075060 | Position Sensors - Distance - Cooling boxes and protective housings for O1D distance sensors | $0.01 | |
| IFM-010075070 | Position Sensors - Distance - OGD precision distance sensor for error proofing applications | $0.01 | |
| IFM-010075080 | Position Sensors - Distance - Distance sensors - PMD Profiler for object profile checking | $0.01 |
