Headline
Magnetic sensors
Magnetic sensors are used for the detection of positions without contact or wear and tear. They are used where very long sensing ranges are required. Since magnetic fields penetrate all non-magnetisable materials, the sensors can detect magnets through walls made of stainless steel, aluminium, plastic or glass.
Features & Benefits
- Actuation possible from different directions
- Meets the interface description CB24I from ZVEI
- Can be connected in series
- Conceal behind stainless steel for enhanced tamper prevention
- Meets highest safety levels to ISO 13849-1 and SILCL 3 to IEC 62061
Additional Notes
| MPN | Sensing range | Output function | Output | Dimensions | Ambient temperature |
|---|---|---|---|---|---|
| MN500S | 8 mm non-flush mountable | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN501S | 8 mm non-flush mountable | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN502S | 8 mm non-flush mountable | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN503S | 8 mm non-flush mountable | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN504S | 8 mm non-flush mountable | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN505S | 8 mm non-flush mountable | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
| MN508S | 8 mm non-flush mountable | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm | -25...80 °C |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-010030010 | Position Sensors - Magnetic - Full-metal sensors | $0.01 | |
| IFM-010030020 | Position Sensors - Magnetic - Cylindrical housings | $0.01 | |
| IFM-010030030 | Position Sensors - Magnetic - Rectangular housings | $0.01 | |
| IFM-010030040 | Position Sensors - Magnetic - Hydraulic cylinder applications | $0.01 | |
| IFM-010030050 | Position Sensors - Magnetic - Speed sensors for drives and axes | $0.01 | |
| IFM-010030070 | Position Sensors - Magnetic - Welding applications | $0.01 |
