Headline
Coaxial tubes for level sensors
A coaxial tube is required for the LR level sensor to function correctly in low dielectric media. The coaxial tube offers effective protection against electromagnetic interference for the reliable detection of oils and oil-based media. In case of operation of the LR level sensor with a coaxial probe, no minimum distances to tank walls and structures in the tank need to be observed.
Features & Benefits
- For use in low dielectric media
- Efficient protection against electromagnetic interference
- Reliable detection of oils and oil-based media
- No minimum distance to the vessel wall required
Additional Notes
| MPN | Product designation | Dimensions | Thread length | Inside diameter | Material |
|---|---|---|---|---|---|
| E43211 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43212 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43213 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43215 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43216 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43217 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43218 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43219 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43220 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43221 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43222 | centring piece | centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301); sealing: NBR fibre-reinforced; mounting aid: POM | |||
| E43223 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43224 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43228 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43229 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43230 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; Fixing strap: stainless steel (1.4310 / 301) | |||
| E43245 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43333 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43334 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; centring piece: PPS fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301) | |||
| E43336 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced | |||
| E43354 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced | |||
| E43355 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced | |||
| E43356 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); sealing: NBR fibre-reinforced; fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced | |||
| E43377 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced | |||
| E43378 | Coaxial tubes for level sensors | Coaxial tubes for level sensors: stainless steel (1.4301 / 304); fixing bracket: stainless steel (1.4310 / 301); centring piece: PPS fibre-reinforced |
