Y connection cables
Y connection cables feature a male connector and two female connectors. They are used for the connection of sensors to splitter boxes and modules. They ensure reliable and permanent sealing of the sensor and splitter connections even when mounted without tools. The integrated end stop protects the O-ring against destruction caused by over-tightening the nut. Even in harsh industrial environments, the connectors are protected against unintended loosening by a special vibration protection. Some types are fitted with highly visible LEDs for operation and switching status indication. Their high-grade stainless steel nut and food-grade sealing materials qualify the Y connection cables of the ecolink EVT series for use in hygienic and wet areas. The Y connection cables are resistant to frequent high-pressure cleaning with aggressive cleaning agents. Thanks to their wide temperature range and their insensitivity to fast temperature changes they are particularly suited for use in the food and beverage industry.
- High protection rating for the requirements of harsh industrial environments
- Reliable sealing even when mounted without tools
- High shock and vibration resistance
- LEDs clearly visible even under bright lighting
- Wide operating temperature range
MPN | Product designation | Connection | Cable structure | Display | Ambient temperature |
---|---|---|---|---|---|
EVF329 | Y connection cable | 1 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF330 | Y connection cable | 2 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF331 | Y connection cable | 5 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF332 | Y connection cable | 1 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF333 | Y connection cable | 2 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF334 | Y connection cable | 5 m MPPE-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVF610 | Y connection cable | 0.15 m MPPE-Cable; M12 Connector | 3 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow; Power: 1 x LED green | -25...100 °C |
EVF693 | Y connection cable | 1 m MPPE-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) / 5 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT329 | Y connection cable | 1 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT330 | Y connection cable | 2 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT331 | Y connection cable | 5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT332 | Y connection cable | 1 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT333 | Y connection cable | 2 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT334 | Y connection cable | 5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT337 | Y connection cable | 5 m PVC-Cable; M12 Connector | 3 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 1 x LED yellow; Power: 1 x LED green | -25...100 °C |
EVT338 | Y connection cable | 0.6 m PVC-Cable; M12 / M8 Connector | 3 x 0,34 mm² (42 x Ø 0,1 mm) | -25...80 °C | |
EVT339 | Y connection cable | 0.6 m PVC-Cable; M12 / M8 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...80 °C | |
EVT340 | Y connection cable | 0.6 m PVC-Cable; M12 / M8 Connector | 3 x 0,34 mm² (42 x Ø 0,1 mm) | -25...80 °C | |
EVT341 | Y connection cable | 0.6 m PVC-Cable; M12 / M8 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...80 °C | |
EVT346 | Y connection cable | 0.3 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | -25...100 °C | |
EVT347 | Y connection cable | 1.2 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | -25...100 °C | |
EVT348 | Y connection cable | 1.6 m PVC-Cable; M12 Connector | 4 x 0,34 mm² | -25...100 °C | |
EVT440 | Y connection cable | 0.5 m PVC-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C | |
EVT606 | Y connection cable | 2 m PVC-Cable; M12 Connector | 3 x 0,34 mm² (42 x Ø 0,1 mm) / 3 x 0,34 mm² (42 x Ø 0,1 mm) | -25...100 °C |
SKU | Description | List price | - |
---|---|---|---|
IFM-090020010 | Cables and Connections - Washdown - Female cordsets for food and beverage applications | $0.01 | |
IFM-090020020 | Cables and Connections - Washdown - Male cordsets for food and beverage applications | $0.01 | |
IFM-090020030 | Cables and Connections - Washdown - Patchcords for food and beverage applications | $0.01 | |
IFM-090020050 | Cables and Connections - Washdown - Wiring blocks for food and beverage applications | $0.01 | |
IFM-090020055 | Cables and Connections - Washdown - Y-splitters for food and beverage applications | $0.01 | |
IFM-090020060 | Cables and Connections - Washdown - Female wirable connectors for food and beverage applications | $0.01 | |
IFM-090020070 | Cables and Connections - Washdown - Male wirable connectors for food and beverage applications | $0.01 |
